本文主要讲解实现了一个CSDN的安卓客户端,主要知识点如下
- java爬虫获取网页数据
- 将java程序打包成jar包
- Fragment+viewpager+TabPageIndicator实现Tab效果
- gestureImageView实现放大缩小图片
- imageLodar实现异步加载图上
- XListView实现下拉刷新
java爬虫获取网页资源
package com.zhy.biz; import java.util.ArrayList;
import java.util.List; import org.jsoup.Jsoup;
import org.jsoup.nodes.Document;
import org.jsoup.nodes.Element;
import org.jsoup.select.Elements; import com.zhy.bean.CommonException;
import com.zhy.bean.NewsItem;
import com.zhy.csdn.DataUtil;
import com.zhy.csdn.URLUtil; /** * 处理NewItem的业务类 * @author zhy * */
public class NewsItemBiz
{ /** * 业界、移动、云计算 * * @param htmlStr * @return * @throws CommonException */ public List<NewsItem> getNewsItems( int newsType , int currentPage) throws CommonException { String urlStr = URLUtil.generateUrl(newsType, currentPage); String htmlStr = DataUtil.doGet(urlStr); List<NewsItem> newsItems = new ArrayList<NewsItem>(); NewsItem newsItem = null; Document doc = Jsoup.parse(htmlStr); Elements units = doc.getElementsByClass("unit"); for (int i = 0; i < units.size(); i++) { newsItem = new NewsItem(); newsItem.setNewsType(newsType); Element unit_ele = units.get(i); Element h1_ele = unit_ele.getElementsByTag("h1").get(0); Element h1_a_ele = h1_ele.child(0); String title = h1_a_ele.text(); String href = h1_a_ele.attr("href"); newsItem.setLink(href); newsItem.setTitle(title); Element h4_ele = unit_ele.getElementsByTag("h4").get(0); Element ago_ele = h4_ele.getElementsByClass("ago").get(0); String date = ago_ele.text(); newsItem.setDate(date); Element dl_ele = unit_ele.getElementsByTag("dl").get(0);// dl Element dt_ele = dl_ele.child(0);// dt try {// 可能没有图片 Element img_ele = dt_ele.child(0); String imgLink = img_ele.child(0).attr("src"); newsItem.setImgLink(imgLink); } catch (IndexOutOfBoundsException e) { } Element content_ele = dl_ele.child(1);// dd String content = content_ele.text(); newsItem.setContent(content); newsItems.add(newsItem); } return newsItems; } }
详细实现参见链接
抓取csdn上的各类别的文章 (制作csdn app 二) - Hongyang - 博客频道 - CSDN.NET
将java项目打包成jar包
参考链接:在Eclipse中将Java项目打包为jar - 闵开慧的个人页面 - 开源中国社区
Fragment+viewpager+TabPageIndicator实现Tab效果
package com.zhy.csdndemo; import com.viewpagerindicator.TabPageIndicator; import android.os.Bundle;
import android.support.v4.app.FragmentActivity;
import android.support.v4.app.FragmentPagerAdapter;
import android.support.v4.view.ViewPager; public class MainActivity extends FragmentActivity
{ private TabPageIndicator mIndicator ; private ViewPager mViewPager ; private FragmentPagerAdapter mAdapter ; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); mIndicator = (TabPageIndicator) findViewById(R.id.id_indicator); mViewPager = (ViewPager) findViewById(R.id.id_pager); mAdapter = new TabAdapter(getSupportFragmentManager()); mViewPager.setAdapter(mAdapter); mIndicator.setViewPager(mViewPager, 0); } }
详细实现参见链接
Android 使用Fragment,ViewPagerIndicator 制作csdn app主要框架 - Hongyang - 博客频道 - CSDN.NET
viewPager的适配器
package com.zhy.csdndemo;import android.support.v4.app.Fragment;
import android.support.v4.app.FragmentManager;
import android.support.v4.app.FragmentPagerAdapter;public class TabAdapter extends FragmentPagerAdapter
{public static final String[] TITLES = new String[] { "业界", "移动", "研发", "程序员杂志", "云计算" };public TabAdapter(FragmentManager fm){super(fm);}@Overridepublic Fragment getItem(int arg0){MainFragment fragment = new MainFragment(arg0+1);return fragment;}@Overridepublic CharSequence getPageTitle(int position){return TITLES[position % TITLES.length];}@Overridepublic int getCount(){return TITLES.length;}}
viewPager中的Fragment实现,其中用xListView实现了获取数据与刷新等功能
package com.zhy.csdndemo;import java.util.ArrayList;
import java.util.List;import me.maxwin.view.IXListViewLoadMore;
import me.maxwin.view.IXListViewRefreshListener;
import me.maxwin.view.XListView;
import android.annotation.SuppressLint;
import android.os.AsyncTask;
import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;import com.zhy.bean.CommonException;
import com.zhy.bean.NewsItem;
import com.zhy.biz.NewsItemBiz;
import com.zhy.csdn.Constaint;
import com.zhy.csdndemo.adapter.NewsItemAdapter;@SuppressLint("ValidFragment")
public class MainFragment extends Fragment implements IXListViewRefreshListener, IXListViewLoadMore
{/*** 默认的newType*/private int newsType = Constaint.NEWS_TYPE_YEJIE;/*** 当前页面*/private int currentPage = 1;/*** 处理新闻的业务类*/private NewsItemBiz mNewsItemBiz;/*** 扩展的ListView*/private XListView mXListView;/*** 数据适配器*/private NewsItemAdapter mAdapter;/*** 数据*/private List<NewsItem> mDatas = new ArrayList<NewsItem>();/*** 获得newType* @param newsType*/public MainFragment(int newsType){this.newsType = newsType;mNewsItemBiz = new NewsItemBiz();}@Overridepublic View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState){return inflater.inflate(R.layout.tab_item_fragment_main, null);}@Overridepublic void onActivityCreated(Bundle savedInstanceState){super.onActivityCreated(savedInstanceState);mAdapter = new NewsItemAdapter(getActivity(), mDatas);/*** 初始化*/mXListView = (XListView) getView().findViewById(R.id.id_xlistView);mXListView.setAdapter(mAdapter);mXListView.setPullRefreshEnable(this);mXListView.setPullLoadEnable(this);//mXListView.NotRefreshAtBegin();/*** 进来时直接刷新*/mXListView.startRefresh();}@Overridepublic void onRefresh(){new LoadDatasTask().execute();}@Overridepublic void onLoadMore(){// TODO Auto-generated method stub}/*** 记载数据的异步任务* @author zhy**/class LoadDatasTask extends AsyncTask<Void, Void, Void>{@Overrideprotected Void doInBackground(Void... params){try{List<NewsItem> newsItems = mNewsItemBiz.getNewsItems(newsType, currentPage);mDatas = newsItems;} catch (CommonException e){// TODO Auto-generated catch blocke.printStackTrace();}return null;}@Overrideprotected void onPostExecute(Void result){mAdapter.addAll(mDatas);mAdapter.notifyDataSetChanged();mXListView.stopRefresh();}}}
xListView的adapter,其中使用了imageLoder
package com.zhy.csdndemo.adapter;import java.util.List;import android.content.Context;
import android.util.Log;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.BaseAdapter;
import android.widget.ImageView;
import android.widget.TextView;import com.nostra13.universalimageloader.core.DisplayImageOptions;
import com.nostra13.universalimageloader.core.ImageLoader;
import com.nostra13.universalimageloader.core.ImageLoaderConfiguration;
import com.nostra13.universalimageloader.core.display.FadeInBitmapDisplayer;
import com.nostra13.universalimageloader.core.display.RoundedBitmapDisplayer;
import com.zhy.bean.NewsItem;
import com.zhy.csdn.DataUtil;
import com.zhy.csdndemo.R;public class NewsItemAdapter extends BaseAdapter
{private LayoutInflater mInflater;private List<NewsItem> mDatas;/*** 使用了github开源的ImageLoad进行了数据加载*/private ImageLoader imageLoader = ImageLoader.getInstance();private DisplayImageOptions options;public NewsItemAdapter(Context context, List<NewsItem> datas){this.mDatas = datas;mInflater = LayoutInflater.from(context);imageLoader.init(ImageLoaderConfiguration.createDefault(context));options = new DisplayImageOptions.Builder().showStubImage(R.drawable.images).showImageForEmptyUri(R.drawable.images).showImageOnFail(R.drawable.images).cacheInMemory().cacheOnDisc().displayer(new RoundedBitmapDisplayer(20)).displayer(new FadeInBitmapDisplayer(300)).build();}public void addAll(List<NewsItem> mDatas){this.mDatas.addAll(mDatas);}@Overridepublic int getCount(){return mDatas.size();}@Overridepublic Object getItem(int position){return mDatas.get(position);}@Overridepublic long getItemId(int position){return position;}@Overridepublic View getView(int position, View convertView, ViewGroup parent){ViewHolder holder = null;if (convertView == null){convertView = mInflater.inflate(R.layout.news_item_yidong, null);holder = new ViewHolder();holder.mContent = (TextView) convertView.findViewById(R.id.id_content);holder.mTitle = (TextView) convertView.findViewById(R.id.id_title);holder.mDate = (TextView) convertView.findViewById(R.id.id_date);holder.mImg = (ImageView) convertView.findViewById(R.id.id_newsImg);convertView.setTag(holder);} else{holder = (ViewHolder) convertView.getTag();}NewsItem newsItem = mDatas.get(position);holder.mTitle.setText(DataUtil.ToDBC(newsItem.getTitle()));holder.mContent.setText(newsItem.getContent());holder.mDate.setText(newsItem.getDate());if (newsItem.getImgLink() != null){holder.mImg.setVisibility(View.VISIBLE);imageLoader.displayImage(newsItem.getImgLink(), holder.mImg, options);} else{holder.mImg.setVisibility(View.GONE);}return convertView;}private final class ViewHolder{TextView mTitle;TextView mContent;ImageView mImg;TextView mDate;}}
参考链接:
客户端上显示csdn上的各类别下的的文章列表 (制作csdn app 三) - Hongyang - 博客频道 - CSDN.NET
