ExpandableListView可以用来表现多层级的listView,本文主要是ExpandableListView的一个简单实现
布局文件
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"xmlns:tools="http://schemas.android.com/tools"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="vertical"><LinearLayout android:layout_height="50dip"android:layout_width="match_parent"android:background="#297DC6"><TextView android:layout_marginLeft="100dip"android:layout_height="wrap_content"android:layout_width="wrap_content"android:text="Email"android:textColor="#ffffff"android:textSize="20sp"android:layout_gravity="center_vertical"/></LinearLayout><ExpandableListView android:id="@+id/list"android:layout_height="match_parent"android:layout_width="match_parent"/></LinearLayout>
MainActivity实现
package com.zj.expandandview;import android.annotation.SuppressLint;
import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.view.Menu;
import android.view.MenuItem;
import android.view.View;
import android.view.ViewGroup;
import android.widget.BaseExpandableListAdapter;
import android.widget.ExpandableListView;
import android.widget.ImageView;
import android.widget.TextView;
import android.widget.ExpandableListView.OnChildClickListener;
import android.widget.ExpandableListView.OnGroupClickListener;public class MainActivity extends Activity {private ExpandableListView expendView;private int []group_click=new int[5];@Overrideprotected void onCreate(Bundle savedInstanceState) {super.onCreate(savedInstanceState);setContentView(R.layout.activity_main);final MyExpendAdapter adapter=new MyExpendAdapter();expendView=(ExpandableListView) findViewById(R.id.list);expendView.setGroupIndicator(null); //设置默认图标不显示expendView.setAdapter(adapter);//一级点击事件expendView.setOnGroupClickListener(new OnGroupClickListener() {@Overridepublic boolean onGroupClick(ExpandableListView parent, View v,int groupPosition, long id) {group_click[groupPosition]+=1;adapter.notifyDataSetChanged();return false;}});//二级点击事件expendView.setOnChildClickListener(new OnChildClickListener() { @Overridepublic boolean onChildClick(ExpandableListView parent, View v,int groupPosition, int childPosition, long id) {//可在这里做点击事件if(groupPosition==0&&childPosition==1){}else if(groupPosition==0&&childPosition==0){//Intent intent=new Intent(MainActivity.this, MailConstactsActivity.class);//startActivity(intent);}else if(groupPosition==1&&childPosition==0){//Intent intent=new Intent(MainActivity.this, MailEditActivity.class);//startActivity(intent);}else if(groupPosition==1&&childPosition==1){//Intent intent=new Intent(MainActivity.this, MailCaogaoxiangActivity.class);//startActivity(intent);}else if(groupPosition==2&&childPosition==0){}else if(groupPosition==2&&childPosition==1){//Intent intent=new Intent(MainActivity.this, MailBoxActivity.class);//intent.putExtra("TYPE", "INBOX");//intent.putExtra("status", 1);//未读//startActivity(intent);}else if(groupPosition==2&&childPosition==2){//Intent intent=new Intent(MainActivity.this, MailBoxActivity.class);//intent.putExtra("TYPE", "INBOX");//intent.putExtra("status", 2);//已读//startActivity(intent);}adapter.notifyDataSetChanged();return false;}});}/*** 适配器* @author Administrator**/private class MyExpendAdapter extends BaseExpandableListAdapter{/*** pic state*///int []group_state=new int[]{R.drawable.group_right,R.drawable.group_down};/*** group title*/String []group_title=new String[]{"联系人","写邮件","收件箱"};/*** child text*/String [][] child_text=new String [][]{{"联系人列表","添加联系人"},{"新邮件","草稿箱"},{"全部邮件","未读邮件","已读邮件"},};int [][] child_icons=new int[][]{{R.drawable.listlianxiren,R.drawable.tianjia},{R.drawable.xieyoujian,R.drawable.caogaoxiang},{R.drawable.all,R.drawable.notread,R.drawable.hasread},};/*** 获取一级标签中二级标签的内容*/@Overridepublic Object getChild(int groupPosition, int childPosition) {return child_text[groupPosition][childPosition];}/*** 获取二级标签ID*/@Overridepublic long getChildId(int groupPosition, int childPosition) {return childPosition;}/*** 对一级标签下的二级标签进行设置*/@SuppressLint("SimpleDateFormat")@Overridepublic View getChildView(int groupPosition, int childPosition,boolean isLastChild, View convertView, ViewGroup parent) {convertView=getLayoutInflater().inflate(R.layout.email_child, null);TextView tv=(TextView) convertView.findViewById(R.id.tv);tv.setText(child_text[groupPosition][childPosition]);ImageView iv=(ImageView) convertView.findViewById(R.id.child_icon);iv.setImageResource(child_icons[groupPosition][childPosition]);return convertView;}/*** 一级标签下二级标签的数量*/@Overridepublic int getChildrenCount(int groupPosition) {return child_text[groupPosition].length;}/*** 获取一级标签内容*/@Overridepublic Object getGroup(int groupPosition) {return group_title[groupPosition];}/*** 一级标签总数*/@Overridepublic int getGroupCount() {return group_title.length;}/*** 一级标签ID*/@Overridepublic long getGroupId(int groupPosition) {return groupPosition;}/*** 对一级标签进行设置*/@Overridepublic View getGroupView(int groupPosition, boolean isExpanded,View convertView, ViewGroup parent) {convertView=getLayoutInflater().inflate(R.layout.email_group, null);ImageView icon=(ImageView) convertView.findViewById(R.id.icon);ImageView iv=(ImageView) convertView.findViewById(R.id.iv);TextView tv=(TextView) convertView.findViewById(R.id.iv_title);iv.setImageResource(R.drawable.group_right);tv.setText(group_title[groupPosition]);if(groupPosition==0){icon.setImageResource(R.drawable.constants);}else if(groupPosition==1){icon.setImageResource(R.drawable.mailto);}else if(groupPosition==2){icon.setImageResource(R.drawable.mailbox);}if(group_click[groupPosition]%2==0){iv.setImageResource(R.drawable.group_right);}else{iv.setImageResource(R.drawable.group_down);}return convertView;}/*** 指定位置相应的组视图*/@Overridepublic boolean hasStableIds() {return true;}/*** 当选择子节点的时候,调用该方法*/@Overridepublic boolean isChildSelectable(int groupPosition, int childPosition) {return true;}}
}
