数据及具体讲解来源:
基于PyTorch搭建CNN实现视频动作分类任务
import torch
import torch.nn as nn
import torchvision.transforms as T
import scipy.io
from torch.utils.data import DataLoader,Dataset
import os
from PIL import Image
from torch.autograd import Variable
import numpy as np"""
加载数据
"""
#获得标签
label_mat = scipy.io.loadmat('./datasets/q3_2_data.mat')
#获得训练集标签
label_train = label_mat['trLb']
print(len(label_train))
#获得验证集标签
label_val = label_mat['valLb']
print(len(label_val))"""
通过Dataset类进行数据预处理
"""
class ActionDataset(Dataset):def __init__(self,root_dir,labels = [],transform=None):"""Args::param root_dir: 数据路径:param labels: 图片标签:param transform: 数据处理函数"""self.root_dir = root_dirself.transform = transformself.length = len(os.listdir(self.root_dir))self.labels = labelsdef __len__(self): #返回数据数量return self.length*3 #一个视频片段包含3帧(3个图片)def __getitem__(self, idx): #图片处理及返回数据folder = idx//3+1 #判断该帧属于第几个视频中imidx = idx%3 + 1 #判断该帧在该视频中是第几帧folder = format(folder,'05d') #将folder格式化,05d代表五位数,若不到五位用0填充imgname = str(imidx) + '.jpg'img_path = os.path.join(self.root_dir,folder,imgname)image = Image.open(img_path)"""当输入标签有值时,说明是训练集和验证集,输出的样本也是有标签的,若没有值,说明是测试集,输出的样本是没有标签的"""if len(self.labels)!=0:Label = self.labels[idx//3][0]-1#如果有对数据的处理先对数据进行处理if self.transform:image = self.transform(image)if len(self.labels)!=0:sample = {'image':image,'img_path':img_path,'Label':Label}else:sample = {'image':image,'img_path':img_path}return sampleimage_datast = ActionDataset(root_dir='./datasets/trainClips/',labels=label_train,transform=T.ToTensor())
# torchvision.transforms中定义了非常多对图像的预处理方法,这里使用的ToTensor方法为将0~255的RGB值映射到0~1的Tensor类型。
# #测试一下
# for i in range(3):
# sample = image_datast[i]
# print(sample['image'].shape)
# print(sample['Label'])
# print(sample['img_path'])"""
Dataloader类进行封装
注意:Windows不要用num_works
"""
#image_dataloader = DataLoader(image_datast,batch_size=4,shuffle=True)
# for i , sample in enumerate(image_dataloader):
# #enumerate(iteration, start):返回一个枚举的对象
# sample['image'] = sample['image']
# print(sample[i,sample['image'].shape,sample['img_path'],'Label'])
# if i == 6:
# break
#训练集
image_dataset_train=ActionDataset(root_dir='./datasets/trainClips/',labels=label_train,transform=T.ToTensor())
image_dataloader_train = DataLoader(image_dataset_train, batch_size=32,shuffle=True)
#验证集
image_dataset_val=ActionDataset(root_dir='./datasets/valClips/',labels=label_val,transform=T.ToTensor())
image_dataloader_val = DataLoader(image_dataset_val, batch_size=32,shuffle=False)
#测试集:没有给定labels
image_dataset_test=ActionDataset(root_dir='./datasets/testClips/',labels=[],transform=T.ToTensor())
image_dataloader_test = DataLoader(image_dataset_test, batch_size=32,shuffle=False)"""
搭建模型
"""dtype = torch.FloatTensor # 这是pytorch所支持的cpu数据类型中的浮点数类型。print_every = 100 # 这个参数用于控制loss的打印频率,因为我们需要在训练过程中不断的对loss进行检测。def reset(m): # 这是模型参数的初始化if hasattr(m, 'reset_parameters'):m.reset_parameters()#数据解释和处理
class Flatten(nn.Module):def forward(self, x):N, C, H, W = x.size() # 读取各个维度。return x.view(N, -1) # -1代表除了特殊声明过的以外的全部维度。fixed_model_base = nn.Sequential(nn.Conv2d(3,8,kernel_size=7,stride=1), ##3*64*64 -> 8*58*58nn.ReLU(inplace=True),nn.MaxPool2d(2, stride = 2), # 8*58*58 -> 8*29*29nn.Conv2d(8, 16, kernel_size=7, stride=1), # 8*29*29 -> 16*23*23nn.ReLU(inplace=True),nn.MaxPool2d(2, stride = 2), # 16*23*23 -> 16*11*11Flatten(),nn.ReLU(inplace=True),nn.Linear(1936, 10) # 1936 = 16*11*11
)
fixed_model = fixed_model_base.type(dtype) #将模型数据转换成pytorch所支持的cpu数据类型中的浮点数类型。
# #测试:
# x = torch.randn(32, 3, 64, 64).type(dtype)
# x_var = Variable(x.type(dtype)) # 需要将其封装为Variable类型。
# ans = fixed_model(x_var)
# print(np.array(ans.size())) # 检查模型输出。
# np.array_equal(np.array(ans.size()), np.array([32, 10]))"""
训练步骤及模块
"""
optimizer = torch.optim.RMSprop(fixed_model_base.parameters(), lr = 0.0001)
loss_fn = nn.CrossEntropyLoss()def train(model,loss_fn,optimizer,dataloader,num_epoch = 1):for epoch in range(num_epoch):check_accuracy(fixed_model,image_dataloader_val) #在验证集验证模型效果model.train() #模型的.train()方法让模型进入训练模式,参数保留梯度,dropout层等部分正常工作for t,sample in enumerate(dataloader):x_var = Variable(sample['image'])y_var = Variable(sample['Label'].long())scores = model(x_var) #得到输出loss = loss_fn(scores,y_var)if (t+1)%print_every ==0:print('t = %d, loss = %.4f' % (t + 1, loss.item()))#三步更新optimizer.zero_grad()loss.backward()optimizer.step()def check_accuracy(model,loader):num_correct = 0num_samples = 0model.eval() # 模型的.eval()方法切换进入评测模式,对应的dropout等部分将停止工作。for t,sample in enumerate(loader):x_var = Variable(sample['image'])y_var = Variable(sample['Label'])scores = model(x_var)_,preds = scores.data.max(1) # 找到可能最高的标签作为输出。num_correct += (preds.numpy() == y_var.numpy()).sum()num_samples += preds.size(0)acc = float(num_correct)/num_samplesprint('Got %d / %d correct (%.2f)' % (num_correct, num_samples, 100 * acc))"""
训练并验证
"""
torch.random.manual_seed(54321)
fixed_model.cpu()
fixed_model.apply(reset)
#pytorch中的model.apply(fn)会递归地将函数fn应用到父模块的每个子模块submodule,也包括model这个父模块自身
fixed_model.train()
train(fixed_model, loss_fn, optimizer,image_dataloader_train, num_epoch=5)
check_accuracy(fixed_model, image_dataloader_val)"""
测试
"""def predict_on_test(model, loader):model.eval()results = open('results.csv', 'w') # 模型预测结果会被放在这里。count = 0results.write('Id' + ',' + 'Class' + '\n')for t, sample in enumerate(loader):x_var = Variable(sample['image'])scores = model(x_var)_, preds = scores.data.max(1)for i in range(len(preds)):results.write(str(count) + ',' + str(preds[i]) + '\n')count += 1results.close()return countcount = predict_on_test(fixed_model, image_dataloader_test) # 放入你想要测试的训练集,然后打开文件去看一看结果吧。
print(count)
