Asp.Net Core AuthorizeAttribute 和AuthorizeFilter 跟进及源码解读

一、前言

IdentityServer4已经分享了一些应用实战的文章，从架构到授权中心的落地应用，也伴随着对IdentityServer4掌握了一些使用规则，但是很多原理性东西还是一知半解，故我这里持续性来带大家一起来解读它的相关源代码，本文先来看看为什么Controller或者Action中添加Authorize或者全局中添加AuthorizeFilter过滤器就可以实现该资源受到保护，需要通过access_token才能通过相关的授权呢？今天我带大家来了解AuthorizeAttribute和AuthorizeFilter的关系及代码解读。

二、代码解读

解读之前我们先来看看下面两种标注授权方式的代码：

标注方式

 [Authorize][HttpGet]public async Task<object> Get(){var userId = User.UserId();return new{name = User.Name(),userId = userId,displayName = User.DisplayName(),merchantId = User.MerchantId(),};}

代码中通过[Authorize]标注来限制该api资源的访问

全局方式

public void ConfigureServices(IServiceCollection services)
{//全局添加AuthorizeFilter 过滤器方式services.AddControllers(options=>options.Filters.Add(new AuthorizeFilter()));services.AddAuthorization();services.AddAuthentication("Bearer").AddIdentityServerAuthentication(options =>{options.Authority = "http://localhost:5000";    //配置Identityserver的授权地址options.RequireHttpsMetadata = false;           //不需要httpsoptions.ApiName = OAuthConfig.UserApi.ApiName;  //api的name，需要和config的名称相同});
}

全局通过添加AuthorizeFilter过滤器方式进行全局api资源的限制

`AuthorizeAttribute`

先来看看AuthorizeAttribute源代码：

[AttributeUsage(AttributeTargets.Class | AttributeTargets.Method, AllowMultiple = true, Inherited = true)]
public class AuthorizeAttribute : Attribute, IAuthorizeData
{/// <summary>/// Initializes a new instance of the <see cref="AuthorizeAttribute"/> class./// </summary>public AuthorizeAttribute() { }/// <summary>/// Initializes a new instance of the <see cref="AuthorizeAttribute"/> class with the specified policy./// </summary>/// <param name="policy">The name of the policy to require for authorization.</param>public AuthorizeAttribute(string policy){Policy = policy;}/// <summary>/// 收取策略/// </summary>public string Policy { get; set; }/// <summary>/// 授权角色/// </summary>public string Roles { get; set; }/// <summary>/// 授权Schemes/// </summary>public string AuthenticationSchemes { get; set; }
}

代码中可以看到AuthorizeAttribute继承了IAuthorizeData抽象接口，该接口主要是授权数据的约束定义，定义了三个数据属性

Prolicy ：授权策略
Roles : 授权角色
AuthenticationSchemes ：授权Schemes 的支持 Asp.Net Core 中的http中间件会根据IAuthorizeData这个来获取有哪些授权过滤器，来实现过滤器的拦截并执行相关代码。我们看看AuthorizeAttribute代码如下：

public interface IAuthorizeData
{/// <summary>/// Gets or sets the policy name that determines access to the resource./// </summary>string Policy { get; set; }/// <summary>/// Gets or sets a comma delimited list of roles that are allowed to access the resource./// </summary>string Roles { get; set; }/// <summary>/// Gets or sets a comma delimited list of schemes from which user information is constructed./// </summary>string AuthenticationSchemes { get; set; }
}

我们再来看看授权中间件（UseAuthorization）的核心代码：

public static IApplicationBuilder UseAuthorization(this IApplicationBuilder app)
{if (app == null){throw new ArgumentNullException(nameof(app));}VerifyServicesRegistered(app);return app.UseMiddleware<AuthorizationMiddleware>();
}

代码中注册了AuthorizationMiddleware这个中间件，AuthorizationMiddleware中间件源代码如下：

 public class AuthorizationMiddleware{// Property key is used by Endpoint routing to determine if Authorization has runprivate const string AuthorizationMiddlewareInvokedWithEndpointKey = "__AuthorizationMiddlewareWithEndpointInvoked";private static readonly object AuthorizationMiddlewareWithEndpointInvokedValue = new object();private readonly RequestDelegate _next;private readonly IAuthorizationPolicyProvider _policyProvider;public AuthorizationMiddleware(RequestDelegate next, IAuthorizationPolicyProvider policyProvider){_next = next ?? throw new ArgumentNullException(nameof(next));_policyProvider = policyProvider ?? throw new ArgumentNullException(nameof(policyProvider));}public async Task Invoke(HttpContext context){if (context == null){throw new ArgumentNullException(nameof(context));}var endpoint = context.GetEndpoint();if (endpoint != null){// EndpointRoutingMiddleware uses this flag to check if the Authorization middleware processed auth metadata on the endpoint.// The Authorization middleware can only make this claim if it observes an actual endpoint.context.Items[AuthorizationMiddlewareInvokedWithEndpointKey] = AuthorizationMiddlewareWithEndpointInvokedValue;}// 通过终结点路由元素IAuthorizeData来获得对于的AuthorizeAttribute并关联到AuthorizeFilter中var authorizeData = endpoint?.Metadata.GetOrderedMetadata<IAuthorizeData>() ?? Array.Empty<IAuthorizeData>();var policy = await AuthorizationPolicy.CombineAsync(_policyProvider, authorizeData);if (policy == null){await _next(context);return;}// Policy evaluator has transient lifetime so it fetched from request services instead of injecting in constructorvar policyEvaluator = context.RequestServices.GetRequiredService<IPolicyEvaluator>();var authenticateResult = await policyEvaluator.AuthenticateAsync(policy, context);// Allow Anonymous skips all authorizationif (endpoint?.Metadata.GetMetadata<IAllowAnonymous>() != null){await _next(context);return;}// Note that the resource will be null if there is no matched endpointvar authorizeResult = await policyEvaluator.AuthorizeAsync(policy, authenticateResult, context, resource: endpoint);if (authorizeResult.Challenged){if (policy.AuthenticationSchemes.Any()){foreach (var scheme in policy.AuthenticationSchemes){await context.ChallengeAsync(scheme);}}else{await context.ChallengeAsync();}return;}else if (authorizeResult.Forbidden){if (policy.AuthenticationSchemes.Any()){foreach (var scheme in policy.AuthenticationSchemes){await context.ForbidAsync(scheme);}}else{await context.ForbidAsync();}return;}await _next(context);}}

代码中核心拦截并获得AuthorizeFilter过滤器的代码

var authorizeData = endpoint?.Metadata.GetOrderedMetadata<IAuthorizeData>() ?? Array.Empty<IAuthorizeData>();

前面我分享过一篇关于 Asp.Net Core EndPoint 终结点路由工作原理解读的文章里面讲解到通过EndPoint终结点路由来获取Controller和Action中的Attribute特性标注，这里也是通过该方法来拦截获取对于的AuthorizeAttribute的. 而获取到相关authorizeData授权数据后，下面的一系列代码都是通过判断来进行AuthorizeAsync授权执行的方法,这里就不详细分享它的授权认证的过程了。细心的同学应该已经发现上面的代码有一个比较特殊的代码：

if (endpoint?.Metadata.GetMetadata<IAllowAnonymous>() != null)
{await _next(context);return;
}

代码中通过endpoint终结点路由来获取是否标注有AllowAnonymous的特性，如果有则直接执行下一个中间件，不进行下面的AuthorizeAsync授权认证方法，这也是为什么Controller和Action上标注AllowAnonymous可以跳过授权认证的原因了。

AuthorizeFilter 源码

有的人会问AuthorizeAttirbute和AuthorizeFilter有什么关系呢？它们是一个东西吗？我们再来看看AuthorizeFilter源代码，代码如下：

public class AuthorizeFilter : IAsyncAuthorizationFilter, IFilterFactory
{/// <summary>/// Initializes a new <see cref="AuthorizeFilter"/> instance./// </summary>public AuthorizeFilter(): this(authorizeData: new[] { new AuthorizeAttribute() }){}/// <summary>/// Initialize a new <see cref="AuthorizeFilter"/> instance./// </summary>/// <param name="policy">Authorization policy to be used.</param>public AuthorizeFilter(AuthorizationPolicy policy){if (policy == null){throw new ArgumentNullException(nameof(policy));}Policy = policy;}/// <summary>/// Initialize a new <see cref="AuthorizeFilter"/> instance./// </summary>/// <param name="policyProvider">The <see cref="IAuthorizationPolicyProvider"/> to use to resolve policy names.</param>/// <param name="authorizeData">The <see cref="IAuthorizeData"/> to combine into an <see cref="IAuthorizeData"/>.</param>public AuthorizeFilter(IAuthorizationPolicyProvider policyProvider, IEnumerable<IAuthorizeData> authorizeData): this(authorizeData){if (policyProvider == null){throw new ArgumentNullException(nameof(policyProvider));}PolicyProvider = policyProvider;}/// <summary>/// Initializes a new instance of <see cref="AuthorizeFilter"/>./// </summary>/// <param name="authorizeData">The <see cref="IAuthorizeData"/> to combine into an <see cref="IAuthorizeData"/>.</param>public AuthorizeFilter(IEnumerable<IAuthorizeData> authorizeData){if (authorizeData == null){throw new ArgumentNullException(nameof(authorizeData));}AuthorizeData = authorizeData;}/// <summary>/// Initializes a new instance of <see cref="AuthorizeFilter"/>./// </summary>/// <param name="policy">The name of the policy to require for authorization.</param>public AuthorizeFilter(string policy): this(new[] { new AuthorizeAttribute(policy) }){}/// <summary>/// The <see cref="IAuthorizationPolicyProvider"/> to use to resolve policy names./// </summary>public IAuthorizationPolicyProvider PolicyProvider { get; }/// <summary>/// The <see cref="IAuthorizeData"/> to combine into an <see cref="IAuthorizeData"/>./// </summary>public IEnumerable<IAuthorizeData> AuthorizeData { get; }/// <summary>/// Gets the authorization policy to be used./// </summary>/// <remarks>/// If<c>null</c>, the policy will be constructed using/// <see cref="AuthorizationPolicy.CombineAsync(IAuthorizationPolicyProvider, IEnumerable{IAuthorizeData})"/>./// </remarks>public AuthorizationPolicy Policy { get; }bool IFilterFactory.IsReusable => true;// Computes the actual policy for this filter using either Policy or PolicyProvider + AuthorizeDataprivate Task<AuthorizationPolicy> ComputePolicyAsync(){if (Policy != null){return Task.FromResult(Policy);}if (PolicyProvider == null){throw new InvalidOperationException(Resources.FormatAuthorizeFilter_AuthorizationPolicyCannotBeCreated(nameof(AuthorizationPolicy),nameof(IAuthorizationPolicyProvider)));}return AuthorizationPolicy.CombineAsync(PolicyProvider, AuthorizeData);}internal async Task<AuthorizationPolicy> GetEffectivePolicyAsync(AuthorizationFilterContext context){// Combine all authorize filters into single effective policy that's only run on the closest filtervar builder = new AuthorizationPolicyBuilder(await ComputePolicyAsync());for (var i = 0; i < context.Filters.Count; i++){if (ReferenceEquals(this, context.Filters[i])){continue;}if (context.Filters[i] is AuthorizeFilter authorizeFilter){// Combine using the explicit policy, or the dynamic policy providerbuilder.Combine(await authorizeFilter.ComputePolicyAsync());}}var endpoint = context.HttpContext.GetEndpoint();if (endpoint != null){// When doing endpoint routing, MVC does not create filters for any authorization specific metadata i.e [Authorize] does not// get translated into AuthorizeFilter. Consequently, there are some rough edges when an application uses a mix of AuthorizeFilter// explicilty configured by the user (e.g. global auth filter), and uses endpoint metadata.// To keep the behavior of AuthFilter identical to pre-endpoint routing, we will gather auth data from endpoint metadata// and produce a policy using this. This would mean we would have effectively run some auth twice, but it maintains compat.var policyProvider = PolicyProvider ?? context.HttpContext.RequestServices.GetRequiredService<IAuthorizationPolicyProvider>();var endpointAuthorizeData = endpoint.Metadata.GetOrderedMetadata<IAuthorizeData>() ?? Array.Empty<IAuthorizeData>();var endpointPolicy = await AuthorizationPolicy.CombineAsync(policyProvider, endpointAuthorizeData);if (endpointPolicy != null){builder.Combine(endpointPolicy);}}return builder.Build();}/// <inheritdoc />public virtual async Task OnAuthorizationAsync(AuthorizationFilterContext context){if (context == null){throw new ArgumentNullException(nameof(context));}if (!context.IsEffectivePolicy(this)){return;}// IMPORTANT: Changes to authorization logic should be mirrored in security's AuthorizationMiddlewarevar effectivePolicy = await GetEffectivePolicyAsync(context);if (effectivePolicy == null){return;}var policyEvaluator = context.HttpContext.RequestServices.GetRequiredService<IPolicyEvaluator>();var authenticateResult = await policyEvaluator.AuthenticateAsync(effectivePolicy, context.HttpContext);// Allow Anonymous skips all authorizationif (HasAllowAnonymous(context)){return;}var authorizeResult = await policyEvaluator.AuthorizeAsync(effectivePolicy, authenticateResult, context.HttpContext, context);if (authorizeResult.Challenged){context.Result = new ChallengeResult(effectivePolicy.AuthenticationSchemes.ToArray());}else if (authorizeResult.Forbidden){context.Result = new ForbidResult(effectivePolicy.AuthenticationSchemes.ToArray());}}IFilterMetadata IFilterFactory.CreateInstance(IServiceProvider serviceProvider){if (Policy != null || PolicyProvider != null){// The filter is fully constructed. Use the current instance to authorize.return this;}Debug.Assert(AuthorizeData != null);var policyProvider = serviceProvider.GetRequiredService<IAuthorizationPolicyProvider>();return AuthorizationApplicationModelProvider.GetFilter(policyProvider, AuthorizeData);}private static bool HasAllowAnonymous(AuthorizationFilterContext context){var filters = context.Filters;for (var i = 0; i < filters.Count; i++){if (filters[i] is IAllowAnonymousFilter){return true;}}// When doing endpoint routing, MVC does not add AllowAnonymousFilters for AllowAnonymousAttributes that// were discovered on controllers and actions. To maintain compat with 2.x,// we'll check for the presence of IAllowAnonymous in endpoint metadata.var endpoint = context.HttpContext.GetEndpoint();if (endpoint?.Metadata?.GetMetadata<IAllowAnonymous>() != null){return true;}return false;}}

代码中继承了 IAsyncAuthorizationFilter, IFilterFactory两个抽象接口，分别来看看这两个抽象接口的源代码

`IAsyncAuthorizationFilter`源代码如下：

/// <summary>
/// A filter that asynchronously confirms request authorization.
/// </summary>
public interface IAsyncAuthorizationFilter : IFilterMetadata
{///定义了授权的方法Task OnAuthorizationAsync(AuthorizationFilterContext context);
}

IAsyncAuthorizationFilter代码中继承了IFilterMetadata接口，同时定义了OnAuthorizationAsync抽象方法,子类需要实现该方法，然而AuthorizeFilter中也已经实现了该方法，稍后再来详细讲解该方法，我们再继续看看IFilterFactory抽象接口,代码如下：

public interface IFilterFactory : IFilterMetadata{bool IsReusable { get; }//创建IFilterMetadata 对象方法IFilterMetadata CreateInstance(IServiceProvider serviceProvider);
}

我们回到AuthorizeFilter 源代码中，该源代码中提供了四个构造初始化方法同时包含了AuthorizeData、Policy属性，我们看看它的默认构造方法代码

public class AuthorizeFilter : IAsyncAuthorizationFilter, IFilterFactory
{public IEnumerable<IAuthorizeData> AuthorizeData { get; }//默认构造函数中默认创建了AuthorizeAttribute 对象public AuthorizeFilter(): this(authorizeData: new[] { new AuthorizeAttribute() }){}//赋值AuthorizeDatapublic AuthorizeFilter(IEnumerable<IAuthorizeData> authorizeData){if (authorizeData == null){throw new ArgumentNullException(nameof(authorizeData));}AuthorizeData = authorizeData;}
}

上面的代码中默认的构造函数默认给构建了一个AuthorizeAttribute对象，并且赋值给了IEnumerable<IAuthorizeData>的集合属性; 好了，看到这里AuthorizeFilter过滤器也是默认构造了一个AuthorizeAttribute的对象，也就是构造了授权所需要的IAuthorizeData信息. 同时AuthorizeFilter实现的OnAuthorizationAsync方法中通过GetEffectivePolicyAsync这个方法获得有效的授权策略，并且进行下面的授权AuthenticateAsync的执行AuthorizeFilter代码中提供了HasAllowAnonymous方法来实现是否Controller或者Action上标注了AllowAnonymous特性，用于跳过授权HasAllowAnonymous代码如下：

private static bool HasAllowAnonymous(AuthorizationFilterContext context)
{var filters = context.Filters;for (var i = 0; i < filters.Count; i++){if (filters[i] is IAllowAnonymousFilter){return true;}}//同样通过上下文的endpoint 来获取是否标注了AllowAnonymous特性var endpoint = context.HttpContext.GetEndpoint();if (endpoint?.Metadata?.GetMetadata<IAllowAnonymous>() != null){return true;}return false;
}

到这里我们再回到全局添加过滤器的方式代码：

 services.AddControllers(options=>options.Filters.Add(new AuthorizeFilter()));

分析到这里，我很是好奇，它是怎么全局添加进去的呢？我打开源代码看了下，源代码如下：

public class MvcOptions : IEnumerable<ICompatibilitySwitch>
{public MvcOptions(){CacheProfiles = new Dictionary<string, CacheProfile>(StringComparer.OrdinalIgnoreCase);Conventions = new List<IApplicationModelConvention>();Filters = new FilterCollection();FormatterMappings = new FormatterMappings();InputFormatters = new FormatterCollection<IInputFormatter>();OutputFormatters = new FormatterCollection<IOutputFormatter>();ModelBinderProviders = new List<IModelBinderProvider>();ModelBindingMessageProvider = new DefaultModelBindingMessageProvider();ModelMetadataDetailsProviders = new List<IMetadataDetailsProvider>();ModelValidatorProviders = new List<IModelValidatorProvider>();ValueProviderFactories = new List<IValueProviderFactory>();}//过滤器集合public FilterCollection Filters { get; }
}

FilterCollection相关核心代码如下：

public class FilterCollection : Collection<IFilterMetadata>
{public IFilterMetadata Add<TFilterType>() where TFilterType : IFilterMetadata{return Add(typeof(TFilterType));}//其他核心代码为贴出来
}

代码中提供了Add方法，约束了IFilterMetadata类型的对象，这也是上面的过滤器中为什么都继承了IFilterMetadata的原因。到这里代码解读和实现原理已经分析完了，如果有分析不到位之处还请多多指教！！！

结论：授权中间件通过获取IAuthorizeData来获取AuthorizeAttribute对象相关的授权信息，并构造授权策略对象进行授权认证的，而AuthorizeFilter过滤器也会默认添加AuthorizeAttribute的授权相关数据IAuthorizeData并实现OnAuthorizationAsync方法，同时中间件中通过授权策略提供者IAuthorizationPolicyProvider来获得对于的授权策略进行授权认证.
