引言：

过去几周我一直在涉足深度学习领域，尤其是卷积神经网络模型。最近，谷歌围绕街景多位数字识别技术发布了一篇不错的paper。该文章描述了一个用于提取街景门牌号的单个端到端神经网络系统。然后，作者阐述了基于同样的网络结构如何来突破谷歌验证码识别系统的准确率。
为了亲身体验神经网络的实现，我决定尝试设计一个可以解决类似问题的系统：国内车牌号自动识别系统。设计这样一个系统的原因有3点：

我应该能够参照谷歌那篇paper搭建一个同样的或者类似的网络架构：谷歌提供的那个网络架构在验证码识别上相当不错，那么讲道理的话，用它来识别车牌号应该也会很给力。拥有一个知名的网络架构将会大大地简化我学习CNN的步骤。
我可以很容易地生成训练数据（车牌数）。训练神经网络存在一个很大的问题就是需要大量的标签样本。通常要训练好一个网络就需要几十万张标记过的图片。
好奇心。传统的车牌号自动识别系统依赖于自己编写算法来实现车牌定位，标准化，分割和字符识别等功能。照这样的话，实现这些系统的代码可能达到上千行。然而，我比较感兴趣的是，如何使用相对较少的代码和最少的专业领域知识来开发一个不错的系统。

开发该项目的环境要求有Python,Tensorflow,OpenCV和NumPy等软件。源代码在这里。

首先项目结构及成果图：

合成图片

genplate.py

为了训练任何一个神经网络，必须提供一套拥有正确输出的训练数据。

文本和车牌背景国内正常的车牌格式，但是文本颜色必须比车牌颜色更深一些。这是为了模拟真实场景的光线变化。最后再加入一些噪音，这样不仅能够解释真实传感器的噪音，而且能够避免过多依赖于锐化的轮廓边界而看到的将会是离焦的输入图片。font目录导入了字体包、image导入了车牌背景及噪声图片。

车牌变换采用了一种基于随机滚转、倾斜、偏转、平移以及缩放的仿射变换。每个参数允许的范围是车牌号可能被看到的所有情况的集合。比如，偏转比滚转允许变化更多（你更可能看到一辆汽车在拐弯而不是翻转到一边）。


import PIL
from PIL import ImageFont
from PIL import Image
from PIL import ImageDraw
import cv2;
import numpy as np;
import os;
from math import *# 生成车牌
# font = ImageFont.truetype("Arial-Bold.ttf",14)index = {"京": 0, "沪": 1, "津": 2, "渝": 3, "冀": 4, "晋": 5, "蒙": 6, "辽": 7, "吉": 8, "黑": 9, "苏": 10, "浙": 11, "皖": 12,"闽": 13, "赣": 14, "鲁": 15, "豫": 16, "鄂": 17, "湘": 18, "粤": 19, "桂": 20, "琼": 21, "川": 22, "贵": 23, "云": 24,"藏": 25, "陕": 26, "甘": 27, "青": 28, "宁": 29, "新": 30, "0": 31, "1": 32, "2": 33, "3": 34, "4": 35, "5": 36,"6": 37, "7": 38, "8": 39, "9": 40, "A": 41, "B": 42, "C": 43, "D": 44, "E": 45, "F": 46, "G": 47, "H": 48,"J": 49, "K": 50, "L": 51, "M": 52, "N": 53, "P": 54, "Q": 55, "R": 56, "S": 57, "T": 58, "U": 59, "V": 60,"W": 61, "X": 62, "Y": 63, "Z": 64};chars = ["京", "沪", "津", "渝", "冀", "晋", "蒙", "辽", "吉", "黑", "苏", "浙", "皖", "闽", "赣", "鲁", "豫", "鄂", "湘", "粤", "桂","琼", "川", "贵", "云", "藏", "陕", "甘", "青", "宁", "新", "0", "1", "2", "3", "4", "5", "6", "7", "8", "9", "A","B", "C", "D", "E", "F", "G", "H", "J", "K", "L", "M", "N", "P", "Q", "R", "S", "T", "U", "V", "W", "X","Y", "Z"];def AddSmudginess(img, Smu):rows = r(Smu.shape[0] - 50)cols = r(Smu.shape[1] - 50)adder = Smu[rows:rows + 50, cols:cols + 50];adder = cv2.resize(adder, (50, 50));#   adder = cv2.bitwise_not(adder)img = cv2.resize(img,(50,50))img = cv2.bitwise_not(img)img = cv2.bitwise_and(adder, img)img = cv2.bitwise_not(img)return img
def rot(img,angel,shape,max_angel):""" 使图像轻微的畸变img 输入图像factor 畸变的参数size 为图片的目标尺寸"""size_o = [shape[1],shape[0]]size = (shape[1]+ int(shape[0]*cos((float(max_angel )/180) * 3.14)),shape[0])interval = abs( int( sin((float(angel) /180) * 3.14)* shape[0]));pts1 = np.float32([[0,0],[0,size_o[1]],[size_o[0],0],[size_o[0],size_o[1]]])if(angel>0):pts2 = np.float32([[interval,0],[0,size[1]  ],[size[0],0  ],[size[0]-interval,size_o[1]]])else:pts2 = np.float32([[0,0],[interval,size[1]  ],[size[0]-interval,0  ],[size[0],size_o[1]]])M  = cv2.getPerspectiveTransform(pts1,pts2);dst = cv2.warpPerspective(img,M,size);return dst;
def rotRandrom(img, factor, size):shape = size;pts1 = np.float32([[0, 0], [0, shape[0]], [shape[1], 0], [shape[1], shape[0]]])pts2 = np.float32([[r(factor), r(factor)], [ r(factor), shape[0] - r(factor)], [shape[1] - r(factor),  r(factor)],[shape[1] - r(factor), shape[0] - r(factor)]])M = cv2.getPerspectiveTransform(pts1, pts2);dst = cv2.warpPerspective(img, M, size);return dst;
def tfactor(img):hsv = cv2.cvtColor(img,cv2.COLOR_BGR2HSV);hsv[:,:,0] = hsv[:,:,0]*(0.8+ np.random.random()*0.2);hsv[:,:,1] = hsv[:,:,1]*(0.3+ np.random.random()*0.7);hsv[:,:,2] = hsv[:,:,2]*(0.2+ np.random.random()*0.8);img = cv2.cvtColor(hsv,cv2.COLOR_HSV2BGR);return img
def random_envirment(img,data_set):index=r(len(data_set))env = cv2.imread(data_set[index])env = cv2.resize(env,(img.shape[1],img.shape[0]))bak = (img==0);bak = bak.astype(np.uint8)*255;inv = cv2.bitwise_and(bak,env)img = cv2.bitwise_or(inv,img)return img
def GenCh(f,val):img=Image.new("RGB", (45,70),(255,255,255))draw = ImageDraw.Draw(img)draw.text((0, 3),val,(0,0,0),font=f)img =  img.resize((23,70))A = np.array(img)return A
def GenCh1(f,val):img=Image.new("RGB", (23,70),(255,255,255))draw = ImageDraw.Draw(img)#draw.text((0, 2),val.decode('utf-8'),(0,0,0),font=f)draw.text((0, 2),val,(0,0,0),font=f)A = np.array(img)return A
def AddGauss(img, level):return cv2.blur(img, (level * 2 + 1, level * 2 + 1));def r(val):return int(np.random.random() * val)def AddNoiseSingleChannel(single):diff = 255-single.max();noise = np.random.normal(0,1+r(6),single.shape);noise = (noise - noise.min())/(noise.max()-noise.min())noise= diff*noise;noise= noise.astype(np.uint8)dst = single + noisereturn dstdef addNoise(img,sdev = 0.5,avg=10):img[:,:,0] =  AddNoiseSingleChannel(img[:,:,0]);img[:,:,1] =  AddNoiseSingleChannel(img[:,:,1]);img[:,:,2] =  AddNoiseSingleChannel(img[:,:,2]);return img;class GenPlate:def __init__(self,fontCh,fontEng,NoPlates):self.fontC =  ImageFont.truetype(fontCh,43,0);self.fontE =  ImageFont.truetype(fontEng,60,0);self.img=np.array(Image.new("RGB", (226,70),(255,255,255)))self.bg  = cv2.resize(cv2.imread("./images/template.bmp"),(226,70));self.smu = cv2.imread("./images/smu2.jpg");self.noplates_path = [];for parent,parent_folder,filenames in os.walk(NoPlates):for filename in filenames:path = parent+"/"+filename;self.noplates_path.append(path);def draw(self,val):offset= 2 ;self.img[0:70,offset+8:offset+8+23]= GenCh(self.fontC,val[0]);self.img[0:70,offset+8+23+6:offset+8+23+6+23]= GenCh1(self.fontE,val[1]);for i in range(5):base = offset+8+23+6+23+17 +i*23 + i*6 ;self.img[0:70, base  : base+23]= GenCh1(self.fontE,val[i+2]);return self.imgdef generate(self,text):if len(text) == 7:fg = self.draw(text.encode('utf-8').decode(encoding="utf-8"));fg = cv2.bitwise_not(fg);com = cv2.bitwise_or(fg,self.bg);com = rot(com,r(60)-30,com.shape,30);com = rotRandrom(com,10,(com.shape[1],com.shape[0]));#com = AddSmudginess(com,self.smu)com = tfactor(com)com = random_envirment(com,self.noplates_path);com = AddGauss(com, 1+r(4));com = addNoise(com);return comdef genPlateString(self,pos,val):plateStr = "";box = [0,0,0,0,0,0,0];if(pos!=-1):box[pos]=1;for unit,cpos in zip(box,range(len(box))):if unit == 1:plateStr += valelse:if cpos == 0:plateStr += chars[r(31)]elif cpos == 1:plateStr += chars[41+r(24)]else:plateStr += chars[31 + r(34)]return plateStr;def genBatch(self, batchSize,pos,charRange, outputPath,size):if (not os.path.exists(outputPath)):os.mkdir(outputPath)for i in range(batchSize):plateStr = G.genPlateString(-1,-1)img =  G.generate(plateStr);img = cv2.resize(img,size);cv2.imwrite(outputPath + "/" + str(i).zfill(2) + ".jpg", img);# return img
G = GenPlate("./font/platech.ttf",'./font/platechar.ttf',"./NoPlates")
G.genBatch(15,2,range(31,65),"./plate",(272,72)) #注释原因为每次其他模块运行，若导入该库，都会刷性该函数

inputdata.py 省略....

产生用于训练的数据
# 批量生成车牌，供算法调用

网络结构 # 算法的核心，卷积神经网络

使用的卷积神经网络结构如model.py所示：

import tensorflow as tf
import numpy as np# 算法的核心，卷积神经网络
def inference (images,keep_prob):'''Build the modelArgs:image: image batch,4D tensor,tf.float32,[batch_size,height,width,channels]Returns:output tensor with the computed logits,float,[batch_size,65]'''# conv1with tf.variable_scope('conv1') as scope:weights = tf.get_variable('weights',shape = [3,3,3,32],dtype = tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.1,dtype=tf.float32))conv = tf.nn.conv2d(images,weights,strides=[1,1,1,1],padding='VALID')biases = tf.get_variable('biases',shape=[32],dtype=tf.float32,initializer=tf.constant_initializer(0.1))pre_activation = tf.nn.bias_add(conv,biases)conv1 = tf.nn.relu(pre_activation,name= scope.name)# conv2with tf.variable_scope('conv2') as scope:weights = tf.get_variable('weights',shape=[3,3,32,32],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.1,dtype=tf.float32))conv = tf.nn.conv2d(conv1,weights,strides=[1,1,1,1],padding='VALID')biases = tf.get_variable('biases',shape=[32],dtype=tf.float32,initializer=tf.constant_initializer(0.1))pre_activation = tf.nn.bias_add(conv,biases)conv2 = tf.nn.relu(pre_activation,name= scope.name)with tf.variable_scope('max_pooling1') as scope:pool1 = tf.nn.max_pool(conv2,ksize = [1,2,2,1],strides= [1,2,2,1],padding='VALID',name='pooling1')#conv3with tf.variable_scope('conv3') as scope:weights = tf.get_variable('weights',shape=[3,3,32,64],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.1,dtype=tf.float32))conv = tf.nn.conv2d(pool1,weights,strides=[1,1,1,1],padding='VALID')biases = tf.get_variable('biases',shape=[64],dtype = tf.float32,initializer= tf.constant_initializer(0.1))pre_activation = tf.nn.bias_add(conv,biases)conv3 = tf.nn.relu(pre_activation,name=scope.name)#conv4with tf.variable_scope('conv4') as scope:weights = tf.get_variable('weights',shape=[3,3,64,64],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.1,dtype=tf.float32))conv =tf.nn.conv2d(conv3,weights,strides=[1,1,1,1],padding='VALID')biases = tf.get_variable('biases',shape=[64],dtype=tf.float32,initializer=tf.constant_initializer(0.1))pre_activation = tf.nn.bias_add(conv,biases)conv4 = tf.nn.relu(pre_activation,name=scope.name)with tf.variable_scope('max_pooling2') as scope:pool2 = tf.nn.max_pool(conv4,ksize=[1,2,2,1],strides=[1,2,2,1],padding='VALID',name='pooling2')#conv5with tf.variable_scope('conv5') as scope:weights = tf.get_variable('weights',shape=[3,3,64,128],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.1,dtype=tf.float32))conv =tf.nn.conv2d(pool2,weights,strides=[1,1,1,1],padding='VALID')biases = tf.get_variable('biases',shape=[128],dtype=tf.float32,initializer=tf.constant_initializer(0.1))pre_activation = tf.nn.bias_add(conv,biases)conv5 = tf.nn.relu(pre_activation,name=scope.name)#conv6with tf.variable_scope('conv6') as scope:weights = tf.get_variable('weights',shape=[3,3,128,128],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.1,dtype=tf.float32))conv =tf.nn.conv2d(conv5,weights,strides=[1,1,1,1],padding='VALID')biases = tf.get_variable('biases',shape=[128],dtype=tf.float32,initializer=tf.constant_initializer(0.1))pre_activation = tf.nn.bias_add(conv,biases)conv6 = tf.nn.relu(pre_activation,name=scope.name)#pool3with tf.variable_scope('max_pool3') as scope:pool3 = tf.nn.max_pool(conv6,ksize=[1,2,2,1],strides=[1,2,2,1],padding='VALID',name='pool3')#%%#fc1_flattenwith tf.variable_scope('fc1') as scope:shp = pool3.get_shape()flattened_shape =shp[1].value*shp[2].value*shp[3].valuereshape = tf.reshape(pool3,[-1,flattened_shape])fc1 = tf.nn.dropout(reshape,keep_prob,name='fc1_dropdot')# 全连接层# 第一个全连接层，识别车牌上的省with tf.variable_scope('fc21') as scope:weights = tf.get_variable('weights',shape=[flattened_shape,65],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.005,dtype=tf.float32))biases = tf.get_variable('biases',shape=[65],dtype=tf.float32,initializer = tf.truncated_normal_initializer(0.1))fc21 = tf.matmul(fc1,weights)+biases# 第二个全连接层，识别车牌上的市with tf.variable_scope('fc22') as scope:weights = tf.get_variable('weights',shape=[flattened_shape,65],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.005,dtype=tf.float32))biases = tf.get_variable('biases',shape=[65],dtype=tf.float32,initializer = tf.truncated_normal_initializer(0.1))fc22 = tf.matmul(fc1,weights)+biases# 第三个全连接层，识别车牌第三位的字母或者数字with tf.variable_scope('fc23') as scope:weights = tf.get_variable('weights',shape=[flattened_shape,65],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.005,dtype=tf.float32))biases = tf.get_variable('biases',shape=[65],dtype=tf.float32,initializer = tf.truncated_normal_initializer(0.1))fc23= tf.matmul(fc1,weights)+biaseswith tf.variable_scope('fc24') as scope:weights = tf.get_variable('weights',shape=[flattened_shape,65],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.005,dtype=tf.float32))biases = tf.get_variable('biases',shape=[65],dtype=tf.float32,initializer = tf.truncated_normal_initializer(0.1))fc24 = tf.matmul(fc1,weights)+biaseswith tf.variable_scope('fc25') as scope:weights = tf.get_variable('weights',shape=[flattened_shape,65],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.005,dtype=tf.float32))biases = tf.get_variable('biases',shape=[65],dtype=tf.float32,initializer = tf.truncated_normal_initializer(0.1))fc25 = tf.matmul(fc1,weights)+biaseswith tf.variable_scope('fc26') as scope:weights = tf.get_variable('weights',shape=[flattened_shape,65],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.005,dtype=tf.float32))biases = tf.get_variable('biases',shape=[65],dtype=tf.float32,initializer = tf.truncated_normal_initializer(0.1))fc26 = tf.matmul(fc1,weights)+biaseswith tf.variable_scope('fc27') as scope:weights = tf.get_variable('weights',shape=[flattened_shape,65],dtype=tf.float32,initializer=tf.truncated_normal_initializer(stddev=0.005,dtype=tf.float32))biases = tf.get_variable('biases',shape=[65],dtype=tf.float32,initializer = tf.truncated_normal_initializer(0.1))fc27 = tf.matmul(fc1,weights)+biasesreturn fc21,fc22,fc23,fc24,fc25,fc26,fc27    #shape = [7,batch_size,65]# 卷积神经网络返回的输出层，进行交叉熵计算
def losses(logits1,logits2,logits3,logits4,logits5,logits6,logits7,labels):'''Compute loss from logits and labelsArgs:logits: logits tensor, float, [7*batch_size, 65]labels: label tensor, tf.int32, [7*batch_size]Returns:loss tensor of float type'''labels = tf.convert_to_tensor(labels,tf.int32)with tf.variable_scope('loss1') as scope:cross_entropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits1, labels=labels[:,0], name='xentropy_per_example')#cross_entropy = tf.nn.softmax_cross_entropy_with_logits(logits=logits,labels=labels,name='xentropy_per_example')loss1 = tf.reduce_mean(cross_entropy, name='loss1')tf.summary.scalar(scope.name+'/loss1', loss1)with tf.variable_scope('loss2') as scope:cross_entropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits2, labels=labels[:,1], name='xentropy_per_example')#cross_entropy = tf.nn.softmax_cross_entropy_with_logits(logits=logits,labels=labels,name='xentropy_per_example')loss2 = tf.reduce_mean(cross_entropy, name='loss2')tf.summary.scalar(scope.name+'/loss2', loss2)with tf.variable_scope('loss3') as scope:cross_entropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits3, labels=labels[:,2], name='xentropy_per_example')#cross_entropy = tf.nn.softmax_cross_entropy_with_logits(logits=logits,labels=labels,name='xentropy_per_example')loss3 = tf.reduce_mean(cross_entropy, name='loss3')tf.summary.scalar(scope.name+'/loss3', loss3)with tf.variable_scope('loss4') as scope:cross_entropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits4, labels=labels[:,3], name='xentropy_per_example')#cross_entropy = tf.nn.softmax_cross_entropy_with_logits(logits=logits,labels=labels,name='xentropy_per_example')loss4 = tf.reduce_mean(cross_entropy, name='loss4')tf.summary.scalar(scope.name+'/loss4', loss4)with tf.variable_scope('loss5') as scope:cross_entropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits5, labels=labels[:,4], name='xentropy_per_example')#cross_entropy = tf.nn.softmax_cross_entropy_with_logits(logits=logits,labels=labels,name='xentropy_per_example')loss5 = tf.reduce_mean(cross_entropy, name='loss5')tf.summary.scalar(scope.name+'/loss5', loss5)with tf.variable_scope('loss6') as scope:cross_entropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits6, labels=labels[:,5], name='xentropy_per_example')#cross_entropy = tf.nn.softmax_cross_entropy_with_logits(logits=logits,labels=labels,name='xentropy_per_example')loss6 = tf.reduce_mean(cross_entropy, name='loss6')tf.summary.scalar(scope.name+'/loss6', loss6)with tf.variable_scope('loss7') as scope:cross_entropy = tf.nn.sparse_softmax_cross_entropy_with_logits(logits=logits7, labels=labels[:,6], name='xentropy_per_example')#cross_entropy = tf.nn.softmax_cross_entropy_with_logits(logits=logits,labels=labels,name='xentropy_per_example')loss7 = tf.reduce_mean(cross_entropy, name='loss7')tf.summary.scalar(scope.name+'/loss7', loss7)return loss1,loss2,loss3,loss4,loss5,loss6,loss7# 最优化，自适应梯度下降，进行优化
def trainning( loss1,loss2,loss3,loss4,loss5,loss6,loss7, learning_rate):'''Training ops, the Op returned by this function is what must be passed to'sess.run()' call to cause the model to train.Args:loss: loss tensor, from losses()Returns:train_op: The op for trainning'''with tf.name_scope('optimizer1'):optimizer1 = tf.train.AdamOptimizer(learning_rate= learning_rate)global_step = tf.Variable(0, name='global_step', trainable=False)train_op1 = optimizer1.minimize(loss1, global_step= global_step)with tf.name_scope('optimizer2'):optimizer2 = tf.train.AdamOptimizer(learning_rate= learning_rate)global_step = tf.Variable(0, name='global_step', trainable=False)train_op2 = optimizer2.minimize(loss2, global_step= global_step)with tf.name_scope('optimizer3'):optimizer3 = tf.train.AdamOptimizer(learning_rate= learning_rate)global_step = tf.Variable(0, name='global_step', trainable=False)train_op3 = optimizer3.minimize(loss3, global_step= global_step)with tf.name_scope('optimizer4'):optimizer4 = tf.train.AdamOptimizer(learning_rate= learning_rate)global_step = tf.Variable(0, name='global_step', trainable=False)train_op4 = optimizer4.minimize(loss4, global_step= global_step)with tf.name_scope('optimizer5'):optimizer5 = tf.train.AdamOptimizer(learning_rate= learning_rate)global_step = tf.Variable(0, name='global_step', trainable=False)train_op5 = optimizer5.minimize(loss5, global_step= global_step)with tf.name_scope('optimizer6'):optimizer6 = tf.train.AdamOptimizer(learning_rate= learning_rate)global_step = tf.Variable(0, name='global_step', trainable=False)train_op6 = optimizer6.minimize(loss6, global_step= global_step)with tf.name_scope('optimizer7'):optimizer7 = tf.train.AdamOptimizer(learning_rate= learning_rate)global_step = tf.Variable(0, name='global_step', trainable=False)train_op7 = optimizer7.minimize(loss7, global_step= global_step)return train_op1,train_op2,train_op3,train_op4,train_op5,train_op6,train_op7# 对模型评估
def evaluation(logits1,logits2,logits3,logits4,logits5,logits6,logits7,labels):"""Evaluate the quality of the logits at predicting the label.Args:logits: Logits tensor, float - [batch_size, NUM_CLASSES].labels: Labels tensor, int32 - [batch_size], with values in therange [0, NUM_CLASSES).Returns:A scalar int32 tensor with the number of examples (out of batch_size)that were predicted correctly."""logits_all = tf.concat([logits1,logits2,logits3,logits4,logits5,logits6,logits7],0)labels = tf.convert_to_tensor(labels,tf.int32)labels_all = tf.reshape(tf.transpose(labels),[-1])with tf.variable_scope('accuracy') as scope:correct = tf.nn.in_top_k(logits_all, labels_all, 1)correct = tf.cast(correct, tf.float16)accuracy = tf.reduce_mean(correct)tf.summary.scalar(scope.name+'/accuracy', accuracy)return accuracy

训练模型：train.py

import os
import numpy as np
import tensorflow as tf
from input_data import OCRIter
import model
import time
import datetime# train训练
img_w = 272
img_h = 72
num_label=7
batch_size = 8
# count =30000
count = 500000
learning_rate = 0.0001#默认参数[N,H,W,C]
image_holder = tf.placeholder(tf.float32,[batch_size,img_h,img_w,3])
label_holder = tf.placeholder(tf.int32,[batch_size,7])
keep_prob = tf.placeholder(tf.float32)logs_train_dir = r'H:\GPpython\第三阶段数据分析\神经网络\Licence_plate_recognize\Licence_plate_recognize\train_result'def get_batch():data_batch = OCRIter(batch_size,img_h,img_w)image_batch,label_batch = data_batch.iter()image_batch1 = np.array(image_batch)label_batch1 = np.array(label_batch)return image_batch1,label_batch1def fit():train_logits1, train_logits2, train_logits3, train_logits4, train_logits5, train_logits6, train_logits7 = model.inference(image_holder, keep_prob)train_loss1, train_loss2, train_loss3, train_loss4, train_loss5, train_loss6, train_loss7 = model.losses(train_logits1, train_logits2, train_logits3, train_logits4, train_logits5, train_logits6, train_logits7,label_holder)train_op1, train_op2, train_op3, train_op4, train_op5, train_op6, train_op7 = model.trainning(train_loss1,train_loss2,train_loss3,train_loss4,train_loss5,train_loss6,train_loss7,learning_rate)train_acc = model.evaluation(train_logits1, train_logits2, train_logits3, train_logits4, train_logits5,train_logits6, train_logits7, label_holder)input_image = tf.summary.image('input', image_holder)summary_op = tf.summary.merge(tf.get_collection(tf.GraphKeys.SUMMARIES))sess = tf.Session()train_writer = tf.summary.FileWriter(logs_train_dir, sess.graph)saver = tf.train.Saver()sess.run(tf.global_variables_initializer())start_time1 = time.time()for step in range(count):x_batch, y_batch = get_batch()start_time2 = time.time()time_str = datetime.datetime.now().isoformat()feed_dict = {image_holder: x_batch, label_holder: y_batch, keep_prob: 0.5}_, _, _, _, _, _, _, tra_loss1, tra_loss2, tra_loss3, tra_loss4, tra_loss5, tra_loss6, tra_loss7, acc, summary_str = sess.run([train_op1, train_op2, train_op3, train_op4, train_op5, train_op6, train_op7, train_loss1, train_loss2,train_loss3, train_loss4, train_loss5, train_loss6, train_loss7, train_acc, summary_op], feed_dict)train_writer.add_summary(summary_str, step)duration = time.time() - start_time2tra_all_loss = tra_loss1 + tra_loss2 + tra_loss3 + tra_loss4 + tra_loss5 + tra_loss6 + tra_loss7# print(y_batch)  #仅测试代码训练实际样本与标签是否一致if step % 10 == 0:sec_per_batch = float(duration)print('%s : Step %d,train_loss = %.2f,acc= %.2f,sec/batch=%.3f' % (time_str, step, tra_all_loss, acc, sec_per_batch))if step % 10000 == 0 or (step + 1) == count:checkpoint_path = os.path.join(logs_train_dir, 'model.ckpt')saver.save(sess, checkpoint_path, global_step=step)sess.close()print(time.time() - start_time1)
if __name__ == '__main__':# fit()data,labels = get_batch()print(data.shape)print(labels.shape)print(labels[0])

除了输出层使用ReLU激活函数之外，所有层都采用深度神经网络的标准结构。指示存在的节点使用sigmoid激活函数，典型地用于二值输出。其他输出节点使用softmax贯穿字符（结果是每一列的概率之和为1），是模型化离散概率分布的标准方法。

根据标签和网络输出的交叉熵来定义损失函数。为了数值稳定性，利用softmax_cross_entropy_with_logits和sigmoid_cross_entropy_with_logits将最后一层的激活函数卷入交叉熵的计算。关于对交叉熵详细而直观的介绍可以参考Michael A. Nielsen的free online book中查看这一节。

使用一块nVidia GTX 960m花费大约数小时来训练（train.py），通过CPU的一个后台进程来运行训练数据的生成。

输出处理

import tensorflow as tf
import numpy as np
import os
from PIL import Image
import cv2
import matplotlib.pyplot as plt
import model
import genplate
index = {"京": 0, "沪": 1, "津": 2, "渝": 3, "冀": 4, "晋": 5, "蒙": 6, "辽": 7, "吉": 8, "黑": 9, "苏": 10, "浙": 11, "皖": 12,"闽": 13, "赣": 14, "鲁": 15, "豫": 16, "鄂": 17, "湘": 18, "粤": 19, "桂": 20, "琼": 21, "川": 22, "贵": 23, "云": 24,"藏": 25, "陕": 26, "甘": 27, "青": 28, "宁": 29, "新": 30, "0": 31, "1": 32, "2": 33, "3": 34, "4": 35, "5": 36,"6": 37, "7": 38, "8": 39, "9": 40, "A": 41, "B": 42, "C": 43, "D": 44, "E": 45, "F": 46, "G": 47, "H": 48,"J": 49, "K": 50, "L": 51, "M": 52, "N": 53, "P": 54, "Q": 55, "R": 56, "S": 57, "T": 58, "U": 59, "V": 60,"W": 61, "X": 62, "Y": 63, "Z": 64};chars = ["京", "沪", "津", "渝", "冀", "晋", "蒙", "辽", "吉", "黑", "苏", "浙", "皖", "闽", "赣", "鲁", "豫", "鄂", "湘", "粤", "桂","琼", "川", "贵", "云", "藏", "陕", "甘", "青", "宁", "新", "0", "1", "2", "3", "4", "5", "6", "7", "8", "9", "A","B", "C", "D", "E", "F", "G", "H", "J", "K", "L", "M", "N", "P", "Q", "R", "S", "T", "U", "V", "W", "X","Y", "Z"];
'''
Test one image against the saved models and parameters
'''
global pic
def get_one_image(test):'''Randomly pick one image from training dataReturn: ndarry'''G = genplate.GenPlate("./font/platech.ttf", './font/platechar.ttf', "./NoPlates")G.genBatch(15, 2, range(31, 65), "./plate", (272, 72))  # 注释原因为每次其他模块运行，若导入该库，都会刷性该函数n = len(test)ind =np.random.randint(0,n)img_dir = test[ind]image_show = Image.open(img_dir)plt.imshow(image_show)#image = image.resize([120,30])image = cv2.imread(img_dir)global  picpic = image# cv2.imshow('image', image)# cv2.waitKey(0)img = np.multiply(image,1/255.0)#image = np.array(img)#image = img.transpose(1,0,2)image = np.array([img])print(image.shape)return imagebatch_size = 1
x = tf.placeholder(tf.float32,[batch_size,72,272,3])
keep_prob =tf.placeholder(tf.float32)test_dir = r'H:/GPpython/Licence_plate_recognize/plate/'
test_image = []
for file in os.listdir(test_dir):test_image.append(test_dir + file)
test_image = list(test_image)image_array = get_one_image(test_image)#logit = model.inference(x,keep_prob)
logit1,logit2,logit3,logit4,logit5,logit6,logit7 = model.inference(x,keep_prob)#logit1 = tf.nn.softmax(logit1)
#logit2 = tf.nn.softmax(logit2)
#logit3 = tf.nn.softmax(logit3)
#logit4 = tf.nn.softmax(logit4)
#logit5 = tf.nn.softmax(logit5)
#logit6 = tf.nn.softmax(logit6)
#logit7 = tf.nn.softmax(logit7)logs_train_dir = r'H:/GPpython/Licence_plate_recognize/train_result/'
saver = tf.train.Saver()with tf.Session() as sess:print ("Reading checkpoint...")ckpt = tf.train.get_checkpoint_state(logs_train_dir)if ckpt and ckpt.model_checkpoint_path:global_step = ckpt.model_checkpoint_path.split('/')[-1].split('-')[-1]saver.restore(sess, ckpt.model_checkpoint_path)print('Loading success, global_step is %s' % global_step)else:print('No checkpoint file found')pre1,pre2,pre3,pre4,pre5,pre6,pre7 = sess.run([logit1,logit2,logit3,logit4,logit5,logit6,logit7], feed_dict={x: image_array,keep_prob:1.0})prediction = np.reshape(np.array([pre1,pre2,pre3,pre4,pre5,pre6,pre7]),[-1,65])#prediction = np.array([[pre1],[pre2],[pre3],[pre4],[pre5],[pre6],[pre7]])#print(prediction)max_index = np.argmax(prediction,axis=1)print(max_index)line = ''for i in range(prediction.shape[0]):if i == 0:result = np.argmax(prediction[i][0:31])if i == 1:result = np.argmax(prediction[i][41:65])+41if i > 1:result = np.argmax(prediction[i][31:65])+31line += chars[result]+" "print ('predicted: ' + line)cv2.imshow('pic',pic)
cv2.waitKeyEx(0)
