02使用常规步骤编译NanoPiM1Plus的Android4.4.2

02使用常规步骤编译NanoPiM1Plus的Android4.4.2





大文实验室/大文哥

壹捌陆捌零陆捌捌陆捌贰

21504965 AT qq.com

完成时间：2017/12/5 17:51

版本：V1.0



开发板：NanoPi M1 Plus/zh

SDK：Android4.4.2





按照全志A33平台编译调通的功能：

0、HDMI（只有720p50Hz）

1、U盘（USB摄像头必须在启动到Android自后再插入，否则是黑屏！）

2、TF

3、RJ45/以太网卡

4、AP6212A0的wifi+BT

5、声音

6、MIC

7、GPIO（以后验证）

8、SPI（以后验证）

9、UART（以后验证）

10、CSI接口的摄像头（以后验证）

11、红外（以后验证）





（一）、解压缩SDK：

rootroot@cm-System-Product-Name:~$ cd /home/wwt

rootroot@cm-System-Product-Name:/home/wwt$

rootroot@cm-System-Product-Name:/home/wwt$ mv nanopi-H3-bsp/ nanopi_h3_bsp

rootroot@cm-System-Product-Name:/home/wwt$

rootroot@cm-System-Product-Name:/home/wwt$ cd nanopi_h3_bsp/

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$ ll

总用量 3246640

-rw------- 1 rootroot rootroot 996147200 12月  4 11:17 h3-android-20170608.7z.001

-rw------- 1 rootroot rootroot 996147200 12月  4 11:15 h3-android-20170608.7z.002

-rw------- 1 rootroot rootroot 996147200 12月  4 11:29 h3-android-20170608.7z.003

-rw------- 1 rootroot rootroot  67405448 12月  4 11:19 h3-android-20170608.7z.004

-rw------- 1 rootroot rootroot 268684287 12月  4 11:25 h3-lichee-20170608.7z

-rw------- 1 rootroot rootroot       188 12月  4 11:25 README.txt

-rw------- 1 rootroot rootroot       188 12月  4 11:25 解压方法.txt

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$ 7za x h3-lichee-20170608.7z -r -o./



Extracting  lichee/brandy/u-boot-2011.09/arch/arm/cpu/arm1136/mx31

Extracting  lichee/brandy/u-boot-2011.09/arch/arm/cpu/arm1136

Extracting  lichee/brandy/u-boot-2011.09/arch/arm/cpu

Extracting  lichee/brandy/u-boot-2011.09/arch/arm

Extracting  lichee/brandy/u-boot-2011.09/arch

Extracting  lichee/brandy/u-boot-2011.09/api

Extracting  lichee/brandy/u-boot-2011.09

Extracting  lichee/brandy/toolchain

Extracting  lichee/brandy

Extracting  lichee



Everything is Ok



Folders: 4241

Files: 52956

Size:       949571074

Compressed: 268684287

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$ 7za x h3-android-20170608.7z.001 -r -o./



Extracting  android/art/compiler/dex/quick/arm

Extracting  android/art/compiler/dex/quick

Extracting  android/art/compiler/dex/portable

Extracting  android/art/compiler/dex

Extracting  android/art/compiler

Extracting  android/art/build

Extracting  android/art

Extracting  android/abi/cpp/src

Extracting  android/abi/cpp/include

Extracting  android/abi/cpp

Extracting  android/abi

Extracting  android



Everything is Ok



Folders: 42578

Files: 364611

Size:       9514031537

Compressed: 996147200

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp$









（二）

由于按照常规步骤编译的IMG不能打开NanoPi M1 Plus上面自带的AP6212的A0版本的WIFI+BT。

下面附带上修改记录：



1、

W:\nanopi_h3_bsp\android\device\softwinner\nanopi-h3\bluetooth\libbt\conf\bt_vendor.conf

# UART device port where Bluetooth controller is attached

UartPort = /dev/ttyS2



# Firmware patch file location

FwPatchFilePath = /system/vendor/modules/



#Firmware name

#FwPatchFileName = bcm4339a0.hcd

FwPatchFileName = bcm43438a0.hcd









2、

W:\nanopi_h3_bsp\android\device\softwinner\nanopi-h3\bluetooth\libbt\include\vnd_dolphin-fvd-p1.txt

BLUETOOTH_HCI_USE_USB = TRUE

USE_CONTROLLER_BDADDR = TRUE

SCO_USE_I2S_INTERFACE = FALSE

FW_PATCHFILE_LOCATION = "/system/etc/firmware"

BTVND_DBG = FALSE

BTHW_DBG = TRUE

VNDUSERIAL_DBG = FALSE

UPIO_DBG = FALSE

USB_DBG = TRUE

直接按照全志A33平台的全部替换掉：

BLUETOOTH_UART_DEVICE_PORT = "/dev/ttyS2"

FW_PATCHFILE_LOCATION = "/system/vendor/modules/"

LPM_IDLE_TIMEOUT_MULTIPLE = 5

UART_TARGET_BAUD_RATE = 1500000

BT_WAKE_VIA_PROC = TRUE

#LPM_SLEEP_MODE = FALSE

BTVND_DBG = TRUE

BTHW_DBG = TRUE

VNDUSERIAL_DBG = TRUE

UPIO_DBG = TRUE









3、

W:\nanopi_h3_bsp\android\device\softwinner\nanopi-h3\bluetooth\bdroid_buildcfg.h

/*

 * Copyright (C) 2012 The Android Open Source Project

 *

 * Licensed under the Apache License, Version 2.0 (the "License");

 * you may not use this file except in compliance with the License.

 * You may obtain a copy of the License at

 *

 *      http://www.apache.org/licenses/LICENSE-2.0

 *

 * Unless required by applicable law or agreed to in writing, software

 * distributed under the License is distributed on an "AS IS" BASIS,

 * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.

 * See the License for the specific language governing permissions and

 * limitations under the License.

 */



#ifndef _BDROID_BUILDCFG_H

#define _BDROID_BUILDCFG_H



#define BTM_DEF_LOCAL_NAME "dolphin-p1"



// SERVICE_CLASS:0x5A (Bit17 -Networking,Bit19 - Capturing,Bit20 -Object Transfer,Bit22 -Telephony)

// MAJOR CLASS: COMPUTER

// MINOR CLASS: TABLET

//##define BTA_DM_COD {0x5A, 0x01, 0x1C}



//#define BTIF_HF_SERVICES (BTA_HSP_SERVICE_MASK)

//#define BTIF_HF_SERVICE_NAMES  { BTIF_HSAG_SERVICE_NAME }

#endif









4、SDK默认为realtek8188eu（USB接口的），需要修改为AP6212的A0版本。

W:\nanopi_h3_bsp\android\device\softwinner\nanopi-h3\BoardConfig.mk

# BoardConfig.mk

#

# Product-specific compile-time definitions.

#



include device/softwinner/dolphin-common/BoardConfigCommon.mk



# image related

TARGET_NO_BOOTLOADER := true

TARGET_NO_RECOVERY := false

TARGET_NO_KERNEL := false



INSTALLED_KERNEL_TARGET := kernel

BOARD_KERNEL_BASE := 0x40000000

BOARD_KERNEL_CMDLINE :=

TARGET_USERIMAGES_USE_EXT4 := true

BOARD_FLASH_BLOCK_SIZE := 4096

BOARD_SYSTEMIMAGE_PARTITION_SIZE := 805306368

#BOARD_USERDATAIMAGE_PARTITION_SIZE :=



# wifi and bt configuration

# 1. wifi Configuration

WPA_SUPPLICANT_VERSION := VER_0_8_X

BOARD_WPA_SUPPLICANT_DRIVER := NL80211

BOARD_WPA_SUPPLICANT_PRIVATE_LIB := lib_driver_cmd

BOARD_HOSTAPD_DRIVER        := NL80211

BOARD_HOSTAPD_PRIVATE_LIB   := lib_driver_cmd



#WIFI_VENDOR_NAME    := realtek

#WIFI_MODULE_NAME    := 8188eu

#WIFI_DRIVER_NAME    := 8188eu



WIFI_VENDOR_NAME    := broadcom

WIFI_MODULE_NAME    := ap6212

WIFI_DRIVER_NAME    := bcmdhd



include hardware/broadcom/wlan/bcmdhd/firmware/firmware-bcm.mk



# 2. Bluetooth Configuration

# make sure BOARD_HAVE_BLUETOOTH is true for every bt vendor

#include device/softwinner/common/hardware/realtek/bluetooth/rtl8723bs/firmware/rtlbtfw_cfg.mk

BOARD_HAVE_BLUETOOTH := true

BOARD_BLUETOOTH_BDROID_BUILDCFG_INCLUDE_DIR := device/softwinner/common/









5、语言默认为英文（国际版本），这里修改为简体中文了！

W:\nanopi_h3_bsp\android\device\softwinner\nanopi-h3\nanopi_h3.mk

## default language setting

#PRODUCT_PROPERTY_OVERRIDES += \

#    persist.sys.timezone=Asia/Shanghai \

#    persist.sys.country=US \

#    persist.sys.language=EN



PRODUCT_PROPERTY_OVERRIDES += \

persist.sys.timezone=Asia/Shanghai \

persist.sys.language=zh \

persist.sys.country=CN









6、无效修改（尝试在底部加入导航条！）：

W:\nanopi_h3_bsp\android\frameworks\base\core\res\res\values\config.xml

    <!-- Whether a software navigation bar should be shown. NOTE: in the future this may be

         autodetected from the Configuration. -->

    <bool name="config_showNavigationBar">false</bool>

修改为：

    <!-- Whether a software navigation bar should be shown. NOTE: in the future this may be

         autodetected from the Configuration. -->

    <bool name="config_showNavigationBar">true</bool>









7、AP6212的A0和A1的兼容版本实现：

W:\nanopi_h3_bsp\android\hardware\broadcom\wlan\bcmdhd\firmware\ap6212\device-bcm.mk

#

# Copyright (C) 2008 The Android Open Source Project

#

# Licensed under the Apache License, Version 2.0 (the "License");

# you may not use this file except in compliance with the License.

# You may obtain a copy of the License at

#

#      http://www.apache.org/licenses/LICENSE-2.0

#

# Unless required by applicable law or agreed to in writing, software

# distributed under the License is distributed on an "AS IS" BASIS,

# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.

# See the License for the specific language governing permissions and

# limitations under the License.

#



-include hardware/broadcom/wlan/bcmdhd/config/config-bcm.mk



PRODUCT_COPY_FILES += \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/fw_bcm43438a0.bin:system/vendor/modules/fw_bcm43438a0.bin \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/fw_bcm43438a0_apsta.bin:system/vendor/modules/fw_bcm43438a0_apsta.bin \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/fw_bcm43438a0_p2p.bin:system/vendor/modules/fw_bcm43438a0_p2p.bin \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/fw_bcm43438a1.bin:system/vendor/modules/fw_bcm43438a1.bin \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/fw_bcm43438a1_apsta.bin:system/vendor/modules/fw_bcm43438a1_apsta.bin \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/fw_bcm43438a1_p2p.bin:system/vendor/modules/fw_bcm43438a1_p2p \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/config.txt:system/vendor/modules/config.txt \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/nvram_ap6212.txt:system/vendor/modules/nvram_ap6212.txt \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/nvram.txt:system/vendor/modules/nvram.txt \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/bcm43438a0.hcd:system/vendor/modules/4343a0.hcd \

    hardware/broadcom/wlan/bcmdhd/firmware/ap6212/bcm43438a1.hcd:system/vendor/modules/bcm43430a1.hcd









8、（直接使用官方编译生成的.config）

W:\nanopi_h3_bsp\lichee\linux-3.4\.config









9、可选修改：

W:\nanopi_h3_bsp\lichee\tools\pack\chips\sun8iw7p1\configs\default\env.cfg

bootdelay=3



#default bootcmd, will change at runtime according to key press

bootcmd=run setargs_nand boot_normal#default nand boot



#kernel command arguments

console=ttyS0,115200

nand_root=/dev/block/system

mmc_root=/dev/block/mmcblk0p7

init=/init

loglevel=8

mac=

wifi_mac=

bt_mac=

specialstr=



#set kernel cmdline if boot.img or recovery.img has no cmdline we will use this

setargs_nand=setenv bootargs console=${console} root=${nand_root} init=${init} loglevel=${loglevel} vmalloc=384M partitions=${partitions} mac_addr=${mac} wifi_mac=${wifi_mac} bt_mac=${bt_mac} specialstr=${specialstr} serialno=${serialno}

setargs_mmc=setenv bootargs console=${console} root=${mmc_root} init=${init} loglevel=${loglevel} vmalloc=384M partitions=${partitions} mac_addr=${mac} wifi_mac=${wifi_mac} bt_mac=${bt_mac} specialstr=${specialstr} serialno=${serialno}



#nand command syntax: sunxi_flash read address partition_name read_bytes

#0x40007800 = 0x40008000(kernel entry) - 0x800(boot.img header 2k)

boot_normal=fatload mmc 0:2 0x43000000 script.bin;sunxi_flash read 40007800 boot;boota 40007800 boot

boot_recovery=sunxi_flash read 40007800 recovery;boota 40007800 recovery

boot_fastboot=fastboot



#recovery key

recovery_key_value_max=0x13

recovery_key_value_min=0x10



#fastboot key

fastboot_key_value_max=0x8

fastboot_key_value_min=0x2









10、拷贝当前开发板的sys_config.fex（尝试1080p60Hz失败）

兼容版本

W:\nanopi_h3_bsp\lichee\tools\pack\chips\sun8iw7p1\configs\nanopi-h3\board\sys_config_nanopi-air.fex

W:\nanopi_h3_bsp\lichee\tools\pack\chips\sun8iw7p1\configs\nanopi-h3\board\sys_config_nanopi-m1.fex

W:\nanopi_h3_bsp\lichee\tools\pack\chips\sun8iw7p1\configs\nanopi-h3\board\sys_config_nanopi-m1-plus.fex

W:\nanopi_h3_bsp\lichee\tools\pack\chips\sun8iw7p1\configs\nanopi-h3\board\sys_config_nanopi-neo.fex



W:\nanopi_h3_bsp\lichee\tools\pack\chips\sun8iw7p1\configs\nanopi-h3\sys_config.fex

[boot_disp]

advert_disp = 0

auto_hpd = 1

output_type = 4

hdmi_channel = 0

hdmi_mode = 4

cvbs_channel = 1

cvbs_mode = 11

output_full = 1

hdmi_mode_check = 1



[disp_init]

disp_init_enable = 1

disp_mode = 0

screen0_output_type = 3

screen0_output_mode = 5

screen1_output_type = 2

screen1_output_mode = 14

fb0_format = 0

fb0_width = 0

fb0_height = 0

fb1_format = 0

fb1_width = 0

fb1_height = 0



[hdmi_para]

hdmi_used = 1

hdmi_power = "vcc-hdmi-18"

修改为：

;全志A20的屏幕参数：

;-------------------------------------------------------------------------------

;disp init configuration

;

;disp_mode            (0:screen0<screen0,fb0> 1:screen1<screen1,fb0> 2:two_diff_screen_diff_contents<screen0,screen1,fb0,fb1>

;                      3:two_same_screen_diff_contets<screen0,screen1,fb0> 4:two_diff_screen_same_contents<screen0,screen1,fb0>)

;screenx_output_type  (0:none; 1:lcd; 2:tv; 3:hdmi; 4:vga)

;screenx_output_mode  (used for tv/hdmi output, 0:480i 1:576i 2:480p 3:576p 4:720p50 5:720p60 6:1080i50 7:1080i60 8:1080p24 9:1080p50 10:1080p60 11:pal 14:ntsc)

;screenx_output_mode  (used for vga output, 0:1680*1050 1:1440*900 2:1360*768 3:1280*1024 4:1024*768 5:800*600 6:640*480 10:1920*1080 11:1280*720)

;fbx format           (4:RGB655 5:RGB565 6:RGB556 7:ARGB1555 8:RGBA5551 9:RGB888 10:ARGB8888 12:ARGB4444)

;fbx pixel sequence   (0:ARGB 1:BGRA 2:ABGR 3:RGBA) --- 0 for linux, 2 for android

;lcd0_bright          (lcd0 init bright,the range:[0,256],default:197

;lcd1_bright          (lcd1 init bright,the range:[0,256],default:197

;-------------------------------------------------------------------------------

[boot_disp]

advert_disp = 0

auto_hpd = 1

output_type = 4

hdmi_channel = 0

;hdmi_mode = 4

hdmi_mode = 10

cvbs_channel = 1

cvbs_mode = 11

output_full = 1

hdmi_mode_check = 1



[disp_init]

disp_init_enable = 1

disp_mode = 0

screen0_output_type = 3

;screen0_output_mode = 5

screen0_output_mode = 10

screen1_output_type = 3

screen1_output_mode = 10

fb0_format = 0

fb0_width = 0

fb0_height = 0

fb1_format = 0

fb1_width = 0

fb1_height = 0



[hdmi_para]

hdmi_used = 1

hdmi_power = "vcc-hdmi-18"









11、编译链：

W:\nanopi_h3_bsp\lichee\brandy\toolchain



如果没有拷贝编译链就会在编译内核的时候出错：

  Building modules, stage 2.

  MODPOST 1 modules

WARNING: "drm_release" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_free_key" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_set_manager" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_owner_cleanup" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_mmap" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_owner_clean" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_init" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_platform_exit" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_platform_init" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_err" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_ioctl" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_alloc" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_takedown" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_set_range" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_ut_debug_printk" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_sman_cleanup" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_poll" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_fasync" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

WARNING: "drm_open" [/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko] undefined!

  CC      /home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.mod.o

  LD [M]  /home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko

make[2]: Leaving directory `/home/wwt/nanopi_h3_bsp/lichee/linux-3.4'

make[1]: Leaving directory `/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali/DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm'

cp DX910-SW-99002-r4p0-00rel0/driver/src/devicedrv/mali/mali.ko /home/wwt/nanopi_h3_bsp/lichee/linux-3.4/output/lib/modules/3.4.39/

cp DX910-SW-99002-r4p0-00rel0/driver/src/egl/x11/drm_module/mali_drm/mali_drm.ko /home/wwt/nanopi_h3_bsp/lichee/linux-3.4/output/lib/modules/3.4.39/

if [ 0 -eq 1 ]; then \

cp DX910-SW-99002-r4p0-00rel0/driver/src/devicedrv/ump/ump.ko /home/wwt/nanopi_h3_bsp/lichee/linux-3.4/output/lib/modules/3.4.39/; \

fi

make: Leaving directory `/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/modules/mali'

regenerate rootfs cpio

9895 blocks

10659 blocks

build_ramfs

Copy boot.img to output directory ...

Copy modules to target ...



sun8iw7p1 compile Kernel successful





INFO: build kernel OK.

INFO: build uboot ...

INFO: prepare toolchain ...

Prepare toolchain ...

tar: ./toolchain/gcc-linaro-arm.tar.xz：无法 open: 没有那个文件或目录

tar: Error is not recoverable: exiting now

Prepare toolchain ...

tar: ./toolchain/gcc-linaro-arm.tar.xz：无法 open: 没有那个文件或目录

tar: Error is not recoverable: exiting now

ERROR: build uboot failed

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$ ./build.sh config









（三）编译lichee/内核和Android/系统：

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$ ./build.sh config



Welcome to mkscript setup progress

All available chips:

   0. sun8iw6p1

   1. sun8iw7p1

   2. sun8iw8p1

   3. sun9iw1p1

Choice: 1

All available platforms:

   0. android

   1. dragonboard

   2. linux

Choice: 0

All available business:

   0. dolphin

   1. secure

   2. karaok

Choice: 0

LICHEE_BUSINESS=dolphin

using kernel 'linux-3.4':

==================================

INFO: ----------------------------------------

INFO: build lichee ...

INFO: chip: sun8iw7p1

INFO: platform: android

INFO: business: dolphin

INFO: kernel: linux-3.4

INFO: board:

INFO: output: out/sun8iw7p1/android/

INFO: ----------------------------------------

INFO: build kernel ...

INFO: prepare toolchain ...

Prepare toolchain ...

tar: ./toolchain/gcc-linaro-arm.tar.xz：无法 open: 没有那个文件或目录

tar: Error is not recoverable: exiting now

Building kernel

/home/wwt/nanopi_h3_bsp/lichee/linux-3.4/output/lib/modules/3.4.39-h3

  HOSTCC  scripts/basic/fixdep

  HOSTCC  scripts/kconfig/conf.o

  SHIPPED scripts/kconfig/zconf.tab.c

  SHIPPED scripts/kconfig/zconf.hash.c

  SHIPPED scripts/kconfig/zconf.lex.c

  HOSTCC  scripts/kconfig/zconf.tab.o

  HOSTLD  scripts/kconfig/conf

scripts/kconfig/conf --silentoldconfig Kconfig

  WRAP    arch/arm/include/generated/asm/auxvec.h

  WRAP    arch/arm/include/generated/asm/bitsperlong.h

  WRAP    arch/arm/include/generated/asm/cputime.h

  WRAP    arch/arm/include/generated/asm/emergency-restart.h





 CC      /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/arch/arm/cpu/armv7/sun8iw7/spl/eabi_compat.c ...

make[2]:正在离开目录 `/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/spl'

make -C /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/spl/lib/

make[2]: 正在进入目录 `/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/spl/lib'

make[2]: 没有什么可以做的为 `all'。

make[2]:正在离开目录 `/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/spl/lib'

/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/../toolchain/gcc-arm/bin/arm-linux-gnueabi-gcc -E -g  -Os   -fno-common -ffixed-r8 -msoft-float   -D__KERNEL__ -DCONFIG_SYS_TEXT_BASE="(0x4A000000)" -I/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/include -I/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/include/openssl -fno-builtin -ffreestanding -nostdinc -isystem /home/wwt/nanopi_h3_bsp/lichee/brandy/toolchain/gcc-arm/bin/../lib/gcc/arm-linux-gnueabi/4.6.3/include -pipe  -DCONFIG_ARM -D__ARM__ -mfpu=neon -D__NEON_SIMD__ -marm  -mabi=aapcs-linux -mno-thumb-interwork -mcpu=cortex-a7 -include /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/include/u-boot/u-boot.lds.h -DSBROMSWADDR="(0x480)"  -ansi -D__ASSEMBLY__ -P - </home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/main/sboot.lds >/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/sboot.lds

/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/../toolchain/gcc-arm/bin/arm-linux-gnueabi-ld /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/arch/arm/cpu/armv7/sun8iw7/dram/libchipid.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/arch/arm/cpu/armv7/sun8iw7/dram/libdram.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/arch/arm/cpu/armv7/sun8iw7/mmc/libmmc.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/arch/arm/cpu/armv7/sun8iw7/nand/libnand.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/lib/openssl/libopenssl.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/flash/libflash.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/libs/libgeneric.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/load/libload.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/main/libmain.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/spl/libsource_spl.o /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/spl/lib/libgeneric.o -L /home/wwt/nanopi_h3_bsp/lichee/brandy/toolchain/gcc-arm/bin/../lib/gcc/arm-linux-gnueabi/4.6.3 -lgcc  -T/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/sboot.lds -o sboot.axf -Map sboot.map

/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/../toolchain/gcc-arm/bin/arm-linux-gnueabi-objcopy --gap-fill=0xff -O binary /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/sboot.axf /home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom/sboot.bin

make[1]:正在离开目录 `/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/sunxi_spl/sbrom'

fatal: Not a git repository (or any parent up to mount point /home/wwt)

Stopping at filesystem boundary (GIT_DISCOVERY_ACROSS_FILESYSTEM not set).

build_sboot

"sboot_sun8iw7p1.bin" -> "/home/wwt/nanopi_h3_bsp/lichee/brandy/u-boot-2011.09/../../tools/pack/chips/sun8iw7p1/bin/sboot_sun8iw7p1.bin"

INFO: build uboot ok.

INFO: ----------------------------------------



INFO: build sun8iw7p1 android dolphin lichee OK



INFO: ----------------------------------------



rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$ ll

总用量 36

drwxrwxr-x  4 rootroot rootroot 4096  5月 16  2017 brandy

drwxr-xr-x  3 rootroot rootroot 4096  4月 27  2017 buildroot

-rwxr-xr-x  1 rootroot rootroot   55  1月 16  2017 build.sh

drwxr-xr-x  2 rootroot rootroot 4096  6月  9 10:04 doc

drwxr-xr-x  2 rootroot rootroot 4096  6月  8 18:40 fa_tools

drwxr-xr-x 27 rootroot rootroot 4096 12月  6 15:00 linux-3.4

drwxrwxr-x  3 rootroot rootroot 4096 12月  6 14:52 out

-rw-r--r--  1 rootroot rootroot   66  1月  9  2017 README

drwxrwxr-x  7 rootroot rootroot 4096 12月  6 10:20 tools

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/lichee$ cd ../android/

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$ source build/envsetup.sh

including device/softwinner/nanopi-h3/vendorsetup.sh

including device/softwinner/eagle-fvd-p1/vendorsetup.sh

including device/softwinner/eagle-fvd-p1-secure/vendorsetup.sh

including device/softwinner/common/vendorsetup.sh

including device/softwinner/dolphin-fvd-p1/vendorsetup.sh

including device/lge/mako/vendorsetup.sh

including device/lge/hammerhead/vendorsetup.sh

including device/samsung/manta/vendorsetup.sh

including device/generic/x86/vendorsetup.sh

including device/generic/mips/vendorsetup.sh

including device/generic/armv7-a-neon/vendorsetup.sh

including device/asus/tilapia/vendorsetup.sh

including device/asus/deb/vendorsetup.sh

including device/asus/grouper/vendorsetup.sh

including device/asus/flo/vendorsetup.sh

including sdk/bash_completion/adb.bash

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$ lunch



You're building on Linux



Lunch menu... pick a combo:

     1. aosp_arm-eng

     2. aosp_x86-eng

     3. aosp_mips-eng

     4. vbox_x86-eng

     5. nanopi_h3-eng

     6. eagle_fvd_p1-eng

     7. eagle_fvd_p1_secure-eng

     8. dolphin_fvd_p1-eng

     9. aosp_mako-userdebug

     10. aosp_hammerhead-userdebug

     11. aosp_manta-userdebug

     12. mini_x86-userdebug

     13. mini_mips-userdebug

     14. mini_armv7a_neon-userdebug

     15. aosp_tilapia-userdebug

     16. aosp_deb-userdebug

     17. aosp_grouper-userdebug

     18. aosp_flo-userdebug



Which would you like? [aosp_arm-eng] 5



============================================

PLATFORM_VERSION_CODENAME=REL

PLATFORM_VERSION=4.4.2

TARGET_PRODUCT=nanopi_h3

TARGET_BUILD_VARIANT=eng

TARGET_BUILD_TYPE=release

TARGET_BUILD_APPS=

TARGET_ARCH=arm

TARGET_ARCH_VARIANT=armv7-a-neon

TARGET_CPU_VARIANT=cortex-a7

HOST_ARCH=x86

HOST_OS=linux

HOST_OS_EXTRA=Linux-3.13.0-24-generic-x86_64-with-Ubuntu-14.04-trusty

HOST_BUILD_TYPE=release

BUILD_ID=KOT49H

OUT_DIR=out

============================================



rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$ extract-bsp

/home/wwt/nanopi_h3_bsp/android/device/*/nanopi-h3/bImage copied!

/home/wwt/nanopi_h3_bsp/android/device/*/nanopi-h3/modules copied!

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$ make -j12





aapt: warning: **** string 'widget_unread' has no default or required localization for 'az_AZ' in packages/apps/Email/../../../frameworks/support/v7/gridlayout/res

aapt: warning: **** string 'widget_unread' has no default or required localization for 'normal' in packages/apps/Email/../../../frameworks/support/v7/gridlayout/res

aapt: warning: **** string 'widget_unread' has no default or required localization for 'hdpi' in packages/apps/Email/../../../frameworks/support/v7/gridlayout/res

aapt: warning: **** string 'widget_unread' has no default or required localization for 'xhdpi' in packages/apps/Email/../../../frameworks/support/v7/gridlayout/res

aapt: warning: **** string 'widget_unread' has no default or required localization for 'xxhdpi' in packages/apps/Email/../../../frameworks/support/v7/gridlayout/res

aapt: warning: **** string 'widget_unread' has no default or required localization for 'nodpi' in packages/apps/Email/../../../frameworks/support/v7/gridlayout/res

Warning: AndroidManifest.xml already defines versionCode (in http://schemas.android.com/apk/res/android); using existing value in manifest.

Warning: AndroidManifest.xml already defines minSdkVersion (in http://schemas.android.com/apk/res/android); using existing value in manifest.

Warning: AndroidManifest.xml already defines targetSdkVersion (in http://schemas.android.com/apk/res/android); using existing value in manifest.

target Strip: libwebviewchromium (out/target/product/nanopi-h3/obj/lib/libwebviewchromium.so)

Install: out/target/product/nanopi-h3/system/lib/libwebviewchromium.so

Install: out/target/product/nanopi-h3/system/framework/webviewchromium.jar

Install: out/target/product/nanopi-h3/fake_packages/webview-timestamp

Install: out/target/product/nanopi-h3/system/app/Email.apk

get/product/nanopi-h3/obj/NOTICE_FILES/src

Combining NOTICE files into HTML

Combining NOTICE files into text

Installed file list: out/target/product/nanopi-h3/installed-files.txt

Target system fs image: out/target/product/nanopi-h3/obj/PACKAGING/systemimage_intermediates/system.img

ts

/bin:/opt/jdk1.6.0_45/jre/bin'

t/jdk1.6.0_45/jre/bin

+ ENABLE_SPARSE_IMAGE=

+ '[' -s = -s ']'

+ ENABLE_SPARSE_IMAGE=-s

+ shift

+ '[' 6 -ne 5 -a 6 -ne 6 ']'

+ SRC_DIR=out/target/product/nanopi-h3/system

+ '[' '!' -d out/target/product/nanopi-h3/system ']'

+ OUTPUT_FILE=out/target/product/nanopi-h3/obj/PACKAGING/systemimage_intermediates/system.img

+ EXT_VARIANT=ext4

+ MOUNT_POINT=system

+ SIZE=805306368

+ FC=out/target/product/nanopi-h3/root/file_contexts

+ case $EXT_VARIANT in

+ '[' -z system ']'

+ '[' -z 805306368 ']'

+ '[' -n out/target/product/nanopi-h3/root/file_contexts ']'

+ FCOPT='-S out/target/product/nanopi-h3/root/file_contexts'

nopi-h3/system'

em

make_ext4fs -s -S out/target/product/nanopi-h3/root/file_contexts -l 805306368 -a system out/target/product/nanopi-h3/obj/PACKAGING/systemimage_intermediates/system.img out/target/product/nanopi-h3/system

+ make_ext4fs -s -S out/target/product/nanopi-h3/root/file_contexts -l 805306368 -a system out/target/product/nanopi-h3/obj/PACKAGING/systemimage_intermediates/system.img out/target/product/nanopi-h3/system

Creating filesystem with parameters:

    Size: 805306368

    Block size: 4096

    Blocks per group: 32768

    Inodes per group: 8192

    Inode size: 256

    Journal blocks: 3072

    Label:

    Blocks: 196608

    Block groups: 6

    Reserved block group size: 47

Created filesystem with 1403/49152 inodes and 84282/196608 blocks

+ '[' 0 -ne 0 ']'

Install system fs image: out/target/product/nanopi-h3/system.img

out/target/product/nanopi-h3/system.img+out/target/product/nanopi-h3/obj/PACKAGING/recovery_patch_intermediates/recovery_from_boot.p maxsize=822163584 blocksize=4224 total=335045504 reserve=8308608

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$ pack

============================================

chip       = sun8iw7p1

platform   = android

board      = nanopi-h3

debug      = uart0

mode       = normal

function   = none

sigmode    = none

============================================

copying tools file

copying configs file

copying boot resource

copying boot file

"sys_config.bin" -> "script.bin"

packing for android

normal

/home/wwt/nanopi_h3_bsp/lichee/tools/pack/pctools/linux/eDragonEx/

/home/wwt/nanopi_h3_bsp/lichee/tools/pack/out

Begin Parse sys_partion.fex

Add partion bootloader.fex BOOTLOADER_FEX00

Add partion very bootloader.fex BOOTLOADER_FEX00

FilePath: bootloader.fex

FileLength=5b4400Add partion env.fex ENV_FEX000000000

Add partion very env.fex ENV_FEX000000000

FilePath: env.fex

FileLength=20000Add partion boot.fex BOOT_FEX00000000

Add partion very boot.fex BOOT_FEX00000000

FilePath: boot.fex

FileLength=b81800Add partion system.fex SYSTEM_FEX000000

Add partion very system.fex SYSTEM_FEX000000

FilePath: system.fex

FileLength=13eb0f58Add partion recovery.fex RECOVERY_FEX0000

Add partion very recovery.fex RECOVERY_FEX0000

FilePath: recovery.fex

FileLength=c64800Add partion sysrecovery.fex SYSRECOVERY_FEX0

Add partion diskfs.fex DISKFS_FEX000000

sys_config.fex Len: 0x5a47

config.fex Len: 0x8998

split_xxxx.fex Len: 0x200

sys_partition.fex Len: 0x117a

boot0_nand.fex Len: 0x8000

boot0_sdcard.fex Len: 0x8000

u-boot.fex Len: 0xe4000

fes1.fex Len: 0x31e0

toc1.fex Len: 0x8

toc0.fex Len: 0x8

usbtool.fex Len: 0x23000

aultools.fex Len: 0x26ead

aultls32.fex Len: 0x238dd

cardtool.fex Len: 0x14000

cardscript.fex Len: 0x6ea

sunxi_mbr.fex Len: 0x10000

dlinfo.fex Len: 0x4000

arisc.fex Len: 0x217aa

bootloader.fex Len: 0x5b4400

Vbootloader.fex Len: 0x4

env.fex Len: 0x20000

Venv.fex Len: 0x4

boot.fex Len: 0xb81800

Vboot.fex Len: 0x4

system.fex Len: 0x13eb0f58

Vsystem.fex Len: 0x4

recovery.fex Len: 0xc64800

Vrecovery.fex Len: 0x4

sysrecovery.fex Len: 0xb

diskfs.fex Len: 0x200

BuildImg 0

Dragon execute image.cfg SUCCESS !

cat: ../../../.config: 没有那个文件或目录

----------image is at----------



/home/wwt/nanopi_h3_bsp/lichee/tools/pack/sun8iw7p1_android__uart0.img



pack finish

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$

rootroot@cm-System-Product-Name:/home/wwt/nanopi_h3_bsp/android$





现在就可以直接使用PhoenixSuit V1.10刷机了！
