C++ class实现十字链表存储的图(完整代码)

代码如下:

#include <iostream>
#include <queue>
using namespace std;
typedef int InfoType;
typedef int VertexType;
const int MaxVertexNum = 30;class ArcNode
{friend class OLGraph;friend class VertexNode;
private:int tailvertex, headvertex;ArcNode *hlink, *tlink;InfoType info;
};class VertexNode
{friend class OLGraph;
private:VertexType vertex;ArcNode *firstin, *firstout;
};class OLGraph
{
public:OLGraph() {Init_vis();};void CreateOLgraph();int  GetOut_degree(VertexType v);int  GetIn_degree(VertexType v);void Init_vis(){for (int i = 0; i < MaxVertexNum; i++) vis[i] = false;//注意是MaxVertexNum，不是vertexNum};void DFS_Node(int i);void BFS_Node(int i);void DFStraverse();void BFStraverse();int LocateVertex(VertexType v);//通过结点信息查找其序号void Visit(int v){cout << xlist[v].vertex << " ";};
private:void DFS(int  i);VertexNode xlist[MaxVertexNum];int vertexNum, edgeNum;bool vis[MaxVertexNum];
};int OLGraph::LocateVertex(VertexType v)
{for (int i = 0; i < vertexNum; i++){if (xlist[i].vertex == v) return i;}
}void OLGraph::CreateOLgraph()
{ArcNode *p;cout << "请输入顶点数和边数" << endl;cin >> vertexNum >> edgeNum;for (int i = 0; i < vertexNum; i++){cout << "请输入第" << i << "个顶点信息:" << endl;cin >> xlist[i].vertex;xlist[i].firstin = nullptr;xlist[i].firstout = nullptr;}cout << "下面输入边表信息" << endl;for (int i = 0; i < edgeNum; i++){VertexType v1, v2;//v1--->v2cout << "输入边<i,j>对应的顶点信息i,j" << endl;cin >> v1 >> v2;int p_v1 = LocateVertex(v1);int p_v2 = LocateVertex(v2);p = new ArcNode;p->tailvertex = p_v1;p->headvertex = p_v2;p->tlink = xlist[p_v1].firstout;xlist[p_v1].firstout = p;p->hlink = xlist[p_v2].firstin;xlist[p_v2].firstin = p;}
}int  OLGraph::GetOut_degree(VertexType v)
{int i = LocateVertex(v);ArcNode *p;int cnt = 0;for (p = xlist[i].firstout; p; p = p->tlink) cnt++;return cnt;
}int OLGraph::GetIn_degree(VertexType v)
{int i = LocateVertex(v);ArcNode *p;int cnt = 0;for (p = xlist[i].firstin; p; p = p->hlink) cnt++;return cnt;
}void OLGraph::DFS(int i)
{vis[i] = true;Visit(i);ArcNode *p;for (p = xlist[i].firstout; p; p = p->tlink){if (!vis[p->headvertex]){vis[p->headvertex] = true;DFS(p->headvertex);}}
}void OLGraph::DFS_Node(int i)
{DFS(i);cout << endl;Init_vis();
}void OLGraph::BFS_Node(int i)
{queue<int>q;vis[i] = true;q.push(i);ArcNode *p;while (q.size()){int t = q.front();q.pop();Visit(t);for (p = xlist[t].firstout; p; p = p->tlink){if (!vis[p->headvertex]){vis[p->headvertex] = true;q.push(p->headvertex);}}}cout << endl;Init_vis();
}void OLGraph::DFStraverse()
{for (int i = 0; i < vertexNum; i++){if (!vis[i]){vis[i] = true;DFS(i);}}cout << endl;Init_vis();
}void OLGraph::BFStraverse()
{for (int i = 0; i < vertexNum; i++){if (!vis[i]){queue<int>q;vis[i] = true;q.push(i);ArcNode *p;while (q.size()){int t = q.front();q.pop();Visit(t);for (p = xlist[t].firstout; p; p = p->tlink){if (!vis[p->headvertex]){vis[p->headvertex] = true;q.push(p->headvertex);}}}}}cout << endl;Init_vis();
}int main()
{OLGraph g;g.CreateOLgraph();cout << "bfs:" << endl;g.BFStraverse();cout << "dfs:" << endl;g.DFStraverse();VertexType  v;cin >> v;cout << "结点" << v << "的入度为:" << endl;cout<<g.GetIn_degree(v)<<endl;cout << "结点" << v << "的出度为:" << endl;cout << g.GetOut_degree(v) << endl;cin >> v;cout << "结点" << v << "的入度为:" << endl;cout << g.GetIn_degree(v) << endl;cout << "结点" << v << "的出度为:" << endl;cout << g.GetOut_degree(v) << endl;int p;cin >> p;g.BFS_Node(p);g.DFS_Node(p);return 0;
}
